FRAME & ATTACHING PARTS
534D-9/534D-10 91344005 1-18
Figure 1-2 Rear Axle & Attaching Parts
PAP19290
ENLARGED VIEW
Fro
n
of M
ach
in
2
4
6
1
3
5
9
10
11
8
22
21
20 12
19
13
18
23
13
24
25
18
17
13
14
15
16
41
43
44
46
47
50
48
51
53
54
49
63
62
61
60 58
59
55
56
48
18
32
31
30
28
27
26
29
33
35
39
37
38
10
40
52
45
102
102
104
105 103
K1
K2
65
34
67
68
36
66
LOWER
UPPER
UPPER
LOWER
t
e
13
42
64
K3
K4
NOTES:
1. CYLINDER BASE END MUST BE FREE TO ROTATE. SHIM
STEERING CYLINDER BASE END AS REQUIRED TO MAINTAIN A
TOTAL MAX. GAP OF 1/16 IN.
2. SHIM BOTTOM KNUCKLES AS REQUIRED TO MAINTAIN NO MORE
THAN 1/32 IN MOVEMENT. SHIM TOP KNUCKLES AS REQUIRED TO
MAINTAIN NO MORE THAN 1/16 GAP. MUST HAVE A MINIMUM OF
ONE SHIM.
3. INSTALL 5/8 LONG THREAD ON STUD INTO DRIVE HUB,
(SHORTEST LENGTH THREADS ON STUD).
534D-9 S/N 0160000447 & After
534D-10 S/N 0160000448 & After
