JLG 534D-10 Parts Manual User Manual
Page 356
CAB
534D-9/534D-10
91344005
6-16
Figure 6-2 Cab Enclosure Kit Installation
Item
Part Number
Qty.
Description
Rev.
0274497
1
CAB ENCLOSURE KIT INSTALLATION, (534D-9 Before S/N 0160035983
excluding 0160034957, 534D-10 Before S/N 0160035696), (includes all items)
D
1001115867
1
CAB ENCLOSURE KIT INSTALLATION, (534D-9 S/N 0160035983 & After
including 0160034957, 534D-10 S/N 0160035696 & After),
(includes all items except 21 thru 27)
A
1
Ref
CAB ENCLOSURE KIT, (see Figure 6-3 for details)
2
91125106
1
HEATER ASSY, (includes eight items below)
91043429
1
HEATER
70022026
1
HEATER FAN, 7 INCH
82033996
6
FLEX LOOM
80963057
1
TOWER
80963068
2
FEMALE PIN TERMINAL
80963067
2
CABLE SEALS
91031521
2
HEATER MOUNTING BRACKET
88201003
4
HEX HD CAPSCREW, 1/4-20X3/4, GR5
88551009
4
LOCKWASHER, 1/4
3
77143004
4
WHIZ-LOCK SCREW
4
77143006
4
WHIZ-LOCKNUT
5
90206169
1
HEATER HOSE
6
91141459
1
HEATER HOSE
7
86683193
2
HOSE CLAMP
8
86683480
1
BUTT CONNECTOR
9
90200680
1
FAN
10
90027214
6
RUBBER GROMMET
12
88211030
4
SOCKET HD CAPSCREW, #10-24X3/4, GR8
13
77143017
4
WHIX LOCKNUT, #10-24
15
83683085
1
WASHER BOTTLE, (534D-9 Before S/N 0160035983 excluding
0160034957, 534D-10 Before S/N 0160035696)
1001111112
1
WASHER BOTTLE, (534D-9 S/N 0160035983 & After including
0160034957, 534D-10 S/N 0160035696 & After)
16
91146099
1
BOTTLE MOUNTING BRACKET
17
88201003
6
HEX HD CAPSCREW, 1/4-20X3/4, GR5
18
88561009
6
LOCKWASHER, 1/4
19
88501004
6
HEX NUT, 1/4-20
20
77163102
1
INSULATION FEMALE SPADE, 16-14 GA
21
80683073
1
FITTING ADAPTER
22
91403443
1
BARB FITTING, 90 DEGREES
23
80373046
1
FITTING
24
77383540
1
COOLANT RESTRICTOR ORIFICE
25
91083155
1
TRUCK VALVE
26
86671187
2
HEATER HOSE CLAMP
27
85941018
1
SUPPORT CLAMP
28
77363268
2
15 AMP FUSE
29
91143335
1
WIPER-HEATER OPTION HARNESS
30
91123182
1
HEATER HARNESS
31
91361018
1
JUMPER WIRE
32
77383744
1
HEATER SWITCH
33
77383470
1
BOOT
34
80963101
1
WIPER & WASHER SWITCH
534D-9 S/N 0160012443 & After
including 0160012112
534D-10 S/N 0160012392 & After
including 0160012289
