ELECTRICAL
91344005 534D-9/534D-10 10-9
Figure 10-2 Engine Harness Assembly
Item Part Number Qty. Description Rev.
91345041 Ref ENGINE HARNESS ASSY, (includes all items), (no longer available to order,
use 91345079 for replacement) A
91345079 Ref ENGINE HARNESS ASSY, (includes all items)
1 91333013 1 ENGINE HARNESS, (534D-9 S/N 0544217 thru 0160000974, 534D-10
S/N 0366054 thru 0160000896)
91343221 1 ENGINE HARNESS, (534D-9 S/N 0160000975 & After, 534D-10
S/N 0160000897 & After)
2 91365014 1 QUICK START THERMOSTAT ASSY, (includes the following four items)
91363031 1 THERMOSTAT
80963058 1 SHROUD CONNECTOR, (2-wire)
80963069 2 MALE PIN TERMINAL
80963065 2 CABLE SEAL
3 91363066 1 JUMPER WIRE, (534D-9 S/N 0160000700 thru 0160006687,
534D-10 S/N 0160000978 thru 0160006664)
91553066 1 JUMPER WIRE, (534D-9 S/N 0160007027 & After,
534D-10 S/N 0160006855 & After)
4 86883075 1 TUBE FITTING
5 91345008 1 STARTER RELAY ASSY, (includes the following seven items)
77383377 2 RELAY
91331014 1 RELAY MOUNTING BRACKET
88211028 4 SOCKET HD CAPSCREW, #10-24X1/2, GR8
88501612 4 HEX NUT
88561105 4 FLAT WASHER, #10
88551007 4 LOCKWASHER, #10
91373009 1 JUMPER WIRE
6 24741047 1 PRESSURE SWITCH
7 91143315 1 OIL PRESSURE SENDER
8 91081388 1 TAPPED BAR
534D-9 S/N 0544217 thru 0160000853 excluding
0160000700
534D-10 S/N 0366054 thru 0160000974
