JLG 534D-10 Parts Manual - Manual (Page 770)

OPTIONS
534D-9/534D-10 91344005 12-110
Figure 12-28 Auxiliary Hyd Electronics w/LH Tilt/Sway Assembly - 45 Ft Boom
61 57
64
CROWD
R/UP L/DN
VIEW A - A
LIFT
TILT
SWAY
AUX
F B
A
C E
D
BOOM WIRING HARNESS
"TM" MAST UP (ORANGE)
"A" EXTRA (BLUE)
"LT" SIDE SHIFT (RED)
"RT" SWING (GREEN)
"S" MAST (BLACK)
(UNDER DASH)
SW-5
PUSHBUTTON
SPDT MOMENTARY
SW-1
PUSHBUTTON
SPDT MOMENTARY
SW-2
PUSHBUTTON
SPDT MOMENTARY
SW-3
PUSHBUTTON
SPDT MOMENTARY
(1)
(2)
(3)
(5)
SW-4
PUSHBUTTON
SPDT MOMENTARY
5 BUTTON HANDLE
N.O.
N.O.
N.O.
N.O.
N.O.
JUMPER WIRE
30 85
86 87a 87
30 85
86 87a 87
(SWING)
GREEN
(BLACK)
(MAST)
(GREEN)
(SWING)
(YELLOW)
(GROUND)
(GROUND)
YELLOW
(SIDE SHIFT)
RED
(EXTRA)
BLUE
(MAST DOWN)
BLACK
(MAST UP)
ORANGE
VIEWED FROM WIRE
INSERTION END
6 CONTACT SOCKET(ON BOOM HEAD)
RELAY
#2
RELAY
#1
BLACK 16 GA.
(W/PIGGYBACK CONN.)
MAST
UP
(RED)
(SIDE SHIFT)
(BLUE)
(EXTRA)
VIEWED FROM WIRE INSERTION END
"GD" GROUND (YELLOW)
GROUND TO STUD
ON ORBITROL MOUNT
RECEPTICAL CONNECTOR
GROUND TO STUD
ON ORBITROL MOUNT
(6) HANDLE COMMON (BROWN)
MAST
DOWN MAST
UP
GND DOWN
GND UP
ORANGE 14 GA.
BLACK 16 GA.
MAST
DOWN
46
47
47
57
54
53
45
48
55
56
63
49
50
51
52
63 62
60
59
58
A A
MAST
DOWN
MAST UP
L/DN
R/UP
B
B
C
C
D
D
TILT
SWAY
CONNECT TO "SPL ACC"
FROM DASH HARNESS
Before S/N 0160027771
