DECALS
534D-9/534D-10
91344005
11-26
Figure 11-2 Frame Decals - 534D-10
Item
Part Number
Qty.
Description
Rev.
1
3251813
1
MADE IN USA DECAL
2
91143283
1
WARNING DECAL
3
91143285
1
INSTRUCTION DECAL
4
91143284
1
WARNING DECAL
5
91143281
1
WARNING DECAL
6
91143282
3
WARNING DECAL
7
80603026
1
CAUTION DECAL
8
91143286
1
WARNING DECAL
9
91083492
2
OIL WARNING DECAL, (S/N 0160003987 thru 0160034816)
10
91143288
1
HYDRAULIC DECAL, (S/N 0160003987 thru 0160034816)
11
91143162
1
TEST PORT DECAL
12
1704885
1
WEBSITE DECAL
13
1706193
2
534D-10-45 DECAL, (S/N 0160006441 & After)
14
91303047
1
BOOM OPERATOR DECAL
15
91143120
1
INSTRUMENT PANEL DECAL
16
91163130
1
OIL LEVEL DECAL
17
80603022
1
DANGER DECAL
18
90553027
1
WARNING DECAL
19
91343073
1
SERVICE INSTRUCTION PLATE
20
91363128
1
NON SKID FLOOR DECAL
21
90553028
1
WARNING DECAL
22
91083318
1
SWAY DECAL
23
91083317
1
TILT DECAL
27
91343016
1
TURBOCHARGER DECAL
28
91163028
1
SHIFTER DECAL
29
91083314
1
TRACTION DECAL, (S/N 0160003987 thru 0160034816)
30
91163212
1
WARNING DECAL
31
91143182
1
PARK BRAKE DECAL
32
91163184
1
CAPACITY CHART COVER
33
91353006
1
LOAD CHART INSTRUCTIONS
34
91033089
1
HORN DECAL
35
91553063
1
VELCRO STRAP
36
91163087
2
LOAD CHART BRACKET
37
88261017
2
SOCKET BUTTON HD CAPSCREW, 1/4-20X7/8
38
NSS
1
S/N PLATE
40
91023006
1
STABILIZER DECAL, (S/N 0160003987 thru 0160034816)
41
91363140
1
NON SKID FLOOR DECAL
42
91353009
1
LOAD CHART, CARRIAGE, (S/N 0160003987 thru 0160037688)
1001106039
1
LOAD CHART, CARRIAGE, (534D-9 S/N 0160038519 & After, 534D-10
S/N 0160038445 & After)
91353019
1
LOAD CHART, SLOPE PILER, (S/N 0160003987 thru 0160037688)
1001106064
1
LOAD CHART, TILT CARRIAGE, (534D-9 S/N 0160038519 & After, 534D-10
S/N 0160038445 & After)
91353020
1
LOAD CHART, 6 FT MAST, (S/N 0160003987 thru 0160037688)
91353021
1
LOAD CHART, DRYWALL/SWING CARRIAGE, (S/N 0160003987 thru
0160037688)
1001106089
1
LOAD CHART, SWING CARRIAGE, (534D-9 S/N 0160038519 & After,
534D-10 S/N 0160038445 & After)
91353022
1
LOAD CHART, 10 FT TRUSS BOOM, (S/N 0160003987 thru 0160037688)
534D-10 S/N 0160003987 & After
