Brother SC-2000 - Manual (Page 9)

7
SET UP
Installing the Software
Stampcreator P-touch Editor and printer driver
Before stamps can be engraved on the SC-2000, the stamp-editing tool Stampcreator P-touch Editor software or Stampcreator
Express software and the SC-2000 printer driver must be installed.
Follow the procedure described below to install the stamp-editing tool Stampcreator P-touch Editor software onto the
computer.
☞ NOTE: You must have administrator privileges in order to install the Stampcreator
P-touch Editor software and change the baud rate on a computer running
Windows NT 4.0, 2000 or XP.
1 Connect the SC-2000 to the computer’s serial or parallel port, and then turn on only the computer.
2 Insert the Stampcreator P-touch Editor Version 4.0 CD-ROM into the
computer’s CD-ROM drive. A dialog box appears, allowing you to se-
lect which components to install. Click the Stampcreator P-touch Editor
button.
The InstallShield ® Wizard for installing the Stampcreator P-touch Editor
software starts up. When the Welcome dialog box appears, click the
Next button to continue.
If the dialog box does not automatically appear, double-click “My Com-
puter” on the desktop, double-click the icon for the CD-ROM drive con-
taining the CD-ROM, and then double-click “Setup” to display the dia-
log box.
3 When the License Agreement dialog box appears, please read the li-
cense agreement carefully.
If you accept all terms of the preceding license agreement, click the Yes
button to continue.
4 In the Customer Information dialog box, type the necessary information
into the appropriate boxes, and then click the Next button.
If the information has already been registered in Windows
® , it will ap-
pear in the appropriate boxes.
5 In the Choose Destination Location dialog box, if it is OK to install the
Stampcreator P-touch Editor software into the folder shown in the “Des-
tination Folder” box, click the Next button.
6 In the Setup Type dialog box, select the installation method, and then
click the Next button.
