SPECIFICATIONS Continued
See notes on page 7.
UNIT SIZE-SERIES 561C048-A, B 561C048-B, C 561C060-A, B 561C060-B, E
Operating Weight (Lb) 192/198 233/218
ELECTRICAL
Unit Volts—Hertz—Phase 208-230—60—1 208/230—60—3 460—60—3 208-230—60—1 208/230—60—3 460—60—3
Operating Voltage Range* 197—253 187—253 414—506 197—253 187—253 414—506
Compressor— Rated Load Amps 24.4/23.7 13.5/14.1 7.4/7.1 28.9/28.8 18.3/16.0 9.0/8.0
Locked Rotor Amps 140.0/129.0 120.0/105.0 49.5/52.5 165.0/169.0 137.0/125.0 62.0/66.5
Condenser Fan Motor—Full Load Amps 1.4 1.4 0.8 1.4 1.4 0.8
Min Unit Ampacity for Wire Sizing 31.9/31.0 18.3/19.0 10.1/9.7 37.5/37.4 24.3/21.4 12.1/10.8
Min Wire Size (60°C Copper) AWG† 8 14 14 8 12 14
Min Wire Size (75°C Copper) AWG† 10 14 14 8 12 14
Max Wire Length (60°C) (Ft)‡ 95/100 45/48 185/182 80 58/68 150/165
Max Wire Length (75°C) (Ft)‡ 55/60 45/46 175/173 75 55/65 142/157
Max Branch Circuit Fuse Size** 50 25 15 60 35/30 15
COMPRESSOR & REFRIGERANT
Compressor—Manufacturer
Millennium/
Copeland
Copeland/
Millennium
Millennium/
Copeland
Copeland/
Millennium
Type Scroll Scroll Scroll Scroll
Temperature and Current Protection Internal Line Break
Refrigerant—Type and Amount @ 15 Ft R-22 and 6.63/6.38 R-22 and 9.89/8.46
CONDENSER COIL & FAN
Coil Face Area (Sq Ft) 14.8 19.8/16.1
Fins Per In.—Rows—Circuits 22—1—3/17—1—3 25—1—4
Fan Motor—PSC Type, HP and RPM 1/4 and 1125
Volts—Hertz—Phase 208/230—60—1 460—60—1 208/230—60—1 460—60—1
Condenser Airflow (CFM) 3400
OPTIONAL EQUIPMENT
Coastal Filter KAACF0501LRG
Time-Delay Relay KAATD0101TDR
Cycle Protector
Standard/
KSACY0101AAA
KSACY0101AAA
Standard/
KSACY0101AAA
KSACY0101AAA
Low-Ambient Controller P251-0083 (RCD)
Crankcase Heater KAACH1201AAA KAACH1301AAA KAACH1201AAA KAACH1301AAA
Inlet Grille Kit K5ABG1704CMD KSABG1804CMD KSABG2104CMD
Start Assist—Capacitor/Relay Type†† KSAHS1601AAA N/A KSAHS1601AAA N/A
Start Assist—PTC Type KAACS0201PTC N/A KAACS0201PTC N/A
Sound Hood KSASH2001CYL / KSASH2101COP
TXV Kit (RPB) KAATX0601RPB KAATX0701RPB
TXV (Hard Shutoff)†† KSATX0701HSO
Low-Pressure Switch KAALP0101LPS
High-Pressure Switch KSAHI0101HPS
Filter Drier P502-8163S (RCD)
Evaporator Freeze Thermostat‡‡ KAAFT0101AAA
Liquid-Line Solenoid Valve†† KAALS0101LLS
Winter Start Control‡‡ KAAWS0101AAA
MotorMaster® Control*** 32LT660004 (RCD) 32LT660005 (RCD) 32LT660004 (RCD) 32LT660005 (RCD)
Ball Bearing Fan Motor HC40GE230 (RCD) HC40GE461 (RCD) HC40GE230 (RCD) HC40GE461 (RCD)
Thermostat, Auto Changeover,
Non-Programmable, °F/°C,
1-Stage Heat, 1-Stage Cool
TSTATBBNAC01-B
Thermostat, Auto Changeover,
7-Day Programmable, °F/°C,
1-Stage Heat, 1-Stage Cool
TSTATBBPAC01-B
Builder’s Thermostat, Manual Changeover,
Non-Programmable, °F/°C,
1-Stage Heat, 1-Stage Cool
TSTATBBBAC01-B
Outdoor Air Temperature Sensor TSTATXXSEN01-B
Backplate for Non-Programmable Thermostat TSTATXXNBP01
Backplate for Programmable Thermostat TSTATXXPBP01
Backplate for Builder’s Thermostat TSTATXXBBP01
Thermostat Conversion Kit (4 to 5 wire) TSTATXXCNV10
