—14—
COMBINATION RATINGS Continued
* Tested Combination.
† In most cases, only 1 method should be used to achieve TDR function. Using more than 1 method in a system may cause degradation in performance. Use
either the accessory Time-Delay Relay KAATD0101TDR or a furnace equipped with TDR. All Bryant furnaces are equipped with TDR except for the
394HAD.
‡ TXV must be hard shutoff type; based on computer simulation.
NOTES: 1. Ratings are net values reflecting the effects of circulating fan motor heat. Supplemental electric heat is not included.
2. Tested outdoor/indoor combinations have been tested in accordance with DOE test procedures for central air conditioners. Ratings for other com-
binations are determined under DOE computer simulation procedures.
3. Determine actual CFM values obtainable for your system by referring to fan performance data in fan coil or furnace coil literature.
4. Minimum outdoor operating ambient in cooling mode is 55°F (12.8°C), maximum 125°F (51.7°C).
UNIT
SIZE-SERIES
INDOOR
MODEL
TOT. CAP.
BTUH
FACTORY-
SUPPLIED
ENHANCE-
MENT
STANDARD
RATING
BRYANT GAS
FURNACE OR
ACCESSORY
TDR†
ACCESSORY
TXV‡ EERA
048-A, B, C
CK3BA048 45,500 TDR 10.50 — 10.50 9.30
CK3BA060 45,500 TDR 11.00 — 11.00 9.15
COILS + 355MAV060080 VARIABLE-SPEED FURNACE
CK3BA048 45,500 TDR 10.50 — 10.50 9.30
CK3BA060 45,500 TDR 11.00 — 11.00 9.15
CK5A/CK5BA048 45,500 TDR 10.50 — 10.50 9.30
CK5A/CK5BA060 45,500 TDR 10.50 — 10.50 9.15
CK5A/CK5BX060 46,000 TDR 11.00 — 11.00 9.15
COILS + 355MAV060100 VARIABLE-SPEED FURNACE
CC5A/CD5AA060 46,000 TDR 10.50 — 10.50 9.15
CC5A/CD5AC048 45,500 TDR 10.80 — 10.80 9.30
CK3BA048 45,500 TDR 10.80 — 10.80 9.30
CK3BA060 45,500 TDR 11.00 — 11.00 9.15
CK5A/CK5BA048 45,500 TDR 10.80 — 10.80 9.30
CK5A/CK5BA060 45,500 TDR 10.50 — 10.50 9.15
CK5A/CK5BX060 46,000 TDR 11.00 — 11.00 9.15
COILS + 355MAV060120 VARIABLE-SPEED FURNACE
CK3BA048 45,500 TDR 10.80 — 10.80 9.30
CK3BA060 45,500 TDR 11.00 — 11.00 9.15
CK5A/CK5BA060 45,500 TDR 10.50 — 10.50 9.15
CK5A/CK5BW048 45,500 TDR 10.80 — 10.80 9.30
CK5A/CK5BX060 46,000 TDR 11.00 — 11.00 9.15
060-A, B, E
CC5A/CD5AA060 54,500 NONE 10.00 10.50 10.50 9.25
CC5A/CD5AW060* 57,000 NONE 10.00 10.50 10.50 9.40
CE3AA060 57,500 NONE 10.00 10.50 10.50 9.50
CK5A/CK5BA060 54,500 NONE 10.00 10.50 10.50 9.25
CK5A/CK5BN060 54,500 NONE 10.00 10.50 10.50 9.50
CK5A/CK5BX060 57,000 NONE 10.00 10.50 10.50 9.50
CK3BA060 54,500 NONE 10.00 10.50 10.50 9.50
F(A,B)4AN(F,B)060 57,500 TDR 10.00 — 10.00 9.00
FB4ANB070 58,000 TDR 10.50 — 10.50 9.35
FC4BN(F,B)060 57,000 TDR&TXV 10.00 — — 9.00
FC4BNB070 58,000 TDR&TXV 10.50 — — 9.35
FG3AAA060 56,500 NONE 10.00 10.20 10.20 9.35
FK4CNB006 58,000 TDR&TXV 11.50 — — 10.00
COILS + 333(B,J)AV060100 VARIABLE-SPEED FURNACE
CC5A/CD5AA060 54,500 TDR 10.70 — 10.70 9.40
CC5A/CD5AW060 54,500 TDR 10.70 — 10.70 9.65
CK3BA060 54,500 TDR 10.70 — 10.70 9.50
CK5A/CK5BA060 54,500 TDR 10.70 — 10.70 9.25
CK5A/CK5BX060 57,000 TDR 10.70 — 10.70 9.40
COILS + 333(B,J)AV060120 VARIABLE-SPEED FURNACE
CC5A/CD5AA060 54,500 TDR 10.70 — 10.70 9.20
CC5A/CD5AW060 54,500 TDR 10.70 — 10.70 9.50
CK3BA060 54,500 TDR 10.70 — 10.70 9.50
CK5A/CK5BA060 54,500 TDR 10.70 — 10.70 9.25
CK5A/CK5BX060 54,500 TDR 10.70 — 10.70 9.40
