—19—
DETAILED COOLING CAPACITIES* Continued
See notes on page 24.
EVAPORATOR
AIR
CONDENSER ENTERING AIR TEMPERATURES °F
75
85
95
105
115
125
CFM
EWB
Capacity
MBtuh†
Total
Sys
KW**
Capacity
MBtuh†
Total
Sys
KW**
Capacity
MBtuh†
Total
Sys
KW**
Capacity
MBtuh†
Total
Sys
KW**
Capacity
MBtuh†
Total
Sys
KW**
Capacity
MBtuh†
Total
Sys
KW**
Total Sens‡
Total Sens‡
Total Sens‡
Total Sens‡
Total Sens‡
Total Sens‡
561C036-A, B, D, E Outdoor Section With CC5A/CD5AA036 Indoor Section Continued
1050
72
41.3
20.5
3.41
39.1
19.6
3.61
36.8
18.8
3.81
34.5
18.0
4.00
32.2
17.1
4.19
29.9
16.3
4.38
67
37.6
25.8
3.28
35.5
25.0
3.47
33.4
24.1
3.65
31.3
23.3
3.84
29.1
22.4
4.02
27.0
21.6
4.20
62
34.1
31.0
3.16
32.2
30.0
3.33
30.3
29.0
3.51
28.4
28.0
3.69
26.6
26.6
3.87
25.0
25.0
4.06
57
32.8
32.8
3.10
31.2
31.2
3.30
29.7
29.7
3.49
28.2
28.2
3.68
26.6
26.6
3.87
25.0
25.0
4.06
1200
72
42.1
21.4
3.51
39.8
20.6
3.70
37.4
19.7
3.90
35.1
18.9
4.09
32.6
18.0
4.29
30.2
17.2
4.47
67
38.4
27.5
3.37
36.2
26.6
3.56
34.0
25.7
3.74
31.8
24.8
3.93
29.6
23.9
4.11
27.3
23.1
4.29
62
34.9
33.1
3.24
33.0
32.0
3.42
31.0
30.8
3.61
29.2
29.2
3.80
27.5
27.5
3.99
25.8
25.8
4.19
57
34.1
34.1
3.22
32.5
32.5
3.41
30.9
30.9
3.60
29.2
29.2
3.80
27.5
27.5
3.99
25.8
25.8
4.19
1350
72
42.7
22.3
3.59
40.3
21.4
3.79
37.9
20.6
3.98
35.4
19.7
4.18
33.0
18.9
4.37
30.5
18.1
4.56
67
38.9
29.0
3.45
36.7
28.1
3.64
34.4
27.2
3.83
32.1
26.3
4.01
29.8
25.4
4.19
27.6
24.5
4.37
62
35.6
34.9
3.33
33.6
33.5
3.52
31.8
31.8
3.71
30.1
30.1
3.91
28.3
28.3
4.10
26.5
26.5
4.30
57
35.2
35.2
3.32
33.5
33.5
3.51
31.8
31.8
3.71
30.1
30.1
3.91
28.3
28.3
4.11
26.5
26.5
4.30
Multipliers for Determining the Performance With Other Indoor Sections
Indoor
Section
Unit
Size
Cooling
Indoor
Section
Unit
Size
Cooling
Capacity
Power
Capacity
Power
COILS + 355MAV060100 VARIABLE-SPEED FURNACE
COILS + 355MAV060120 VARIABLE-SPEED FURNACE
CC5A/CD5AA
042
0.99
0.92
CC5A/CD5AA
042
0.99
0.92
CC5A/CD5AW
042
0.99
0.92
CD5AW
036
0.99
0.92
CD5AW
036
0.99
0.92
CK5A/CK5BA
042
0.99
0.92
CK5A/CK5BA
042
0.99
0.92
CK5A/CK5BT
042
0.99
0.92
CK5A/CK5BT
042
0.99
0.92
CK5A/CK5BW
036
0.99
0.92
CK5A/CK5BW
036
0.99
0.92
—
—
—
