—16—
DETAILED COOLING CAPACITIES* Continued
See notes on page 24.
EVAPORATOR
AIR
CONDENSER ENTERING AIR TEMPERATURES °F
75
85
95
105
115
125
CFM
EWB
Capacity
MBtuh†
Total
Sys
KW**
Capacity
MBtuh†
Total
Sys
KW**
Capacity
MBtuh†
Total
Sys
KW**
Capacity
MBtuh†
Total
Sys
KW**
Capacity
MBtuh†
Total
Sys
KW**
Capacity
MBtuh†
Total
Sys
KW**
Total Sens‡
Total Sens‡
Total Sens‡
Total Sens‡
Total Sens‡
Total Sens‡
561C024-A, D Outdoor Section With CC5A/CD5AA024 Indoor Section
700
72
27.2
13.2
2.34
25.8
12.6
2.46
24.3
12.0
2.57
22.7
11.5
2.68
21.1
10.9
2.78
19.5
10.3
2.88
67
24.8
16.4
2.25
23.4
15.8
2.36
22.0
15.2
2.47
20.5
14.6
2.57
19.1
14.0
2.67
17.6
13.4
2.76
62
22.4
19.5
2.17
21.1
18.9
2.27
19.8
18.2
2.37
18.5
17.6
2.47
17.2
16.8
2.56
15.9
15.9
2.65
57
21.0
21.0
2.12
20.0
20.0
2.23
19.0
19.0
2.34
18.0
18.0
2.45
17.0
17.0
2.55
15.9
15.9
2.65
800
72
27.8
13.8
2.40
26.3
13.2
2.52
24.7
12.6
2.63
23.1
12.0
2.75
21.5
11.4
2.85
19.8
10.9
2.95
67
25.3
17.4
2.31
23.9
16.8
2.42
22.4
16.2
2.53
20.9
15.6
2.64
19.4
15.0
2.73
17.8
14.4
2.82
62
23.0
20.9
2.23
21.6
20.2
2.33
20.2
19.4
2.44
18.9
18.6
2.53
17.6
17.6
2.63
16.5
16.5
2.73
57
21.9
21.9
2.19
20.9
20.9
2.30
19.8
19.8
2.42
18.7
18.7
2.52
17.6
17.6
2.63
16.5
16.5
2.73
900
72
28.3
14.3
2.46
26.7
13.7
2.58
25.1
13.1
2.69
23.4
12.5
2.80
21.7
11.9
2.91
20.0
11.4
3.00
67
25.8
18.3
2.37
24.3
17.7
2.48
22.7
17.1
2.59
21.2
16.5
2.69
19.6
15.8
2.79
18.0
15.2
2.87
62
23.4
22.0
2.28
22.0
21.3
2.39
20.6
20.4
2.50
19.3
19.3
2.60
18.1
18.1
2.70
16.9
16.9
2.80
57
22.7
22.7
2.26
21.6
21.6
2.37
20.5
20.5
2.49
19.3
19.3
2.60
18.1
18.1
2.70
16.9
16.9
2.81
Multipliers for Determining the Performance With Other Indoor Sections
Indoor
Section
Unit
Size
Cooling
Indoor
Section
Unit
Size
Cooling
Capacity
Power
Capacity
Power
CC5A/CD5AA
024
1.00
1.00
COILS + 333(B,J)AV036060 VARIABLE-SPEED FURNACE
030
1.01
1.00
CC5A/CD5AA
024
1.00
0.92
CC5A/CD5AW
024
1.00
1.00
030
1.01
0.92
030
1.01
1.00
CC5A/CD5AW
030
1.01
0.92
CE3AA
024
1.01
1.00
CK3BA
024
1.00
0.93
030
1.03
1.01
030
1.01
0.93
CF5AA
024
1.01
1.00
CK5A/CK5BA
024
1.00
0.93
CK5A/CK5BA
024
1.00
1.00
030
1.01
0.93
030
1.01
1.01
CK5A/CK5BW
030
1.01
0.93
CK5A/CK5BW
024
1.00
1.00
COILS + 355MAV042040 VARIABLE-SPEED FURNACE
030
1.01
1.01
CC5A/CD5AW
030
1.01
0.95
CK3BA
024
1.00
1.00
CK5A/CK5BW
030
1.01
0.95
030
1.01
1.01
COILS + 355MAV042060 VARIABLE-SPEED FURNACE
F(A,B)4AN(F,C)
024
1.01
1.00
CC5A/CD5AW
024
1.00
0.95
030
1.03
1.00
030
1.01
0.95
FC4BNF
024
1.01
1.00
CK3BA
024
1.00
0.96
030
1.03
1.00
030
1.01
0.95
FF1(B,C,D)NA
024
1.01
1.01
CK5A/CK5BW
024
1.00
0.96
030
1.04
1.02
030
1.01
0.95
FG3AAA
024
0.98
0.99
COILS + 355MAV042080 VARIABLE-SPEED FURNACE
FK4CNF
001
1.04
0.93
CC5A/CD5AW
024
1.00
0.94
002
1.04
0.94
030
1.01
0.94
003
1.05
0.92
CK5A/CK5BW
024
1.00
0.94
—
—
—
030
1.01
0.94
