—5—
SPECIFICATIONS Continued
See notes on page 7.
UNIT SIZE-SERIES 561C036-A, B, E 561C036-B, D 561C036-B 561C042-A, B 561C042-B, C 561C042-B
Operating Weight (Lb) 129/138/138 129/133 133 138/142 142
ELECTRICAL
Unit Volts—Hertz—Phase 208-230—60—1 208/230—60—3 460—60—3 208-230—60—1 208/230—60—3 460—60—3
Operating Voltage Range* 197—253 187—253 414—506 197—253 187—253 414—506
Compressor— Rated Load Amps 16.7/14.8/16.0 10.0/10.6 5.1 20.5/19.7 13.6/12.4 6.2
Locked Rotor Amps 95.0/86.0/81.0 75.0/64.5 33.0 115.0/102.0 91.0/90.0 42.0
Condenser Fan Motor—Full Load Amps 1.4 1.4 0.8 1.4 1.4 0.8
Min Unit Ampacity for Wire Sizing 22.3/19.9/21.4 13.9/14.7 7.2 27.0/26.0 18.4/16.9 8.6
Min Wire Size (60°C Copper) AWG† 12 14 14 10 14 14
Min Wire Size (75°C Copper) AWG† 12 14 14 10 14 14
Max Wire Length (60°C) (Ft)‡ 55/55/58 65/60 250 70/75 45/50 210
Max Wire Length (75°C) (Ft)‡ 50/55/55 62/55 238 70 45/50 200
Max Branch Circuit Fuse Size** 30 20 15 40 25 15
COMPRESSOR & REFRIGERANT
Compressor— Manufacturer
Millennium/
Copeland/Bristol
Copeland/
Millennium
Copeland
Millennium/
Copeland
Copeland/
Millennium
Copeland
Type
Scroll/
Reciprocating/
Reciprocating
Reciprocating/
Scroll
Reciprocating
Scroll/
Reciprocating
Reciprocating/
Scroll
Reciprocating
Temperature and Current Protection Internal Line Break
Refrigerant—Type and Amount @ 15 Ft
R-22 and 4.63/
5.00/4.60
R-22 and 5.00/
4.63 R-22 and 5.00
R-22 and 5.00/
5.13
R-22 and 5.13/
5.00
R-22 and 5.13
CONDENSER COIL & FAN
Coil Face Area (Sq Ft) 9.1 10.7
Fins Per In.—Rows—Circuit
20—1—2/
25—1—2/
25—1—2
25—1—2/
20—1—2
25—1—2
22—1—3/
25—1—3
25—1—3/
22—1—3
25—1—3
Fan Motor—PSC Type, HP and RPM
1/5 and 1125/
1100/1125 1/5 and 1125 1/4 and 1125 1/5 and 1125 1/4 and 1125
Volts—Hertz—Phase 208/230—60—1 460—60—1 208/230—60—1 460—60—1
Condenser Airflow (CFM) 2500 3400
OPTIONAL EQUIPMENT
Coastal Filter KAACF0401MED
Time-Delay Relay KAATD0101TDR
Cycle Protector
Standard/
KSACY0101AAA/
KSACY0101AAA
KSACY0101AAA
Standard/
KSACY0101AAA
KSACY0101AAA
Low-Ambient Controller P251-0083 (RCD)
Crankcase Heater
KAACH1201AAA /
KAACH1001AAA/
KAACH1001AAA
KAACH1201AAA/
KAACH1001AAA
KAACH1101AAA KAACH1201AAA/KAACH1001AAA KAACH1101AAA
Inlet Grille Kit KSABG0804CSM KSABG1004CSM
Start Assist—Capacitor/Relay Type††
KSAHS1501AAA/
KSAHS1001AAA/
KSAHS1101AAA
N/A
KSAHS1501AAA/
KSAHS1301AAA
N/A
Start Assist—PTC Type KAACS0201PTC N/A KAACS0201PTC N/A
Sound Hood
KSASH1901CYL/
KSASH1201COP/
KSASH2001BRL
KSASH1901CYL/
N/A
N/A KSASH1901CYL /KSASH1201COP KSASH1201COP
TXV (RPB) KAATX0501RPB
TXV (Hard Shutoff)†† KSATX0601HSO
Low-Pressure Switch KAALP0101LPS
High-Pressure Switch KSAHI0101HPS
Filter Drier P502-8083S (RCD) P502-8163S (RCD)
Evaporator Freeze Thermostat‡‡ KAAFT0101AAA
Liquid-Line Solenoid Valve†† KAALS0101LLS
Winter Start Control‡‡ KAAWS0101AAA
MotorMaster® Control*** 32LT660004 (RCD) 32LT660005 (RCD) 32LT660004 (RCD) 32LT660005 (RCD)
Ball Bearing Fan Motor HC40GE230 (RCD) HC40GE461 (RCD) HC40GE230 (RCD) HC40GE461 (RCD)
Thermostat, Auto Changeover,
Non-Programmable, °F/°C, 1-Stage Heat,
1-Stage Cool
TSTATBBNAC01-B
Thermostat, Auto Changeover,
7-Day Programmable, °F/°C,
1-Stage Heat, 1-Stage Cool
TSTATBBPAC01-B
Builder’s Thermostat, Manual Changeover,
Non-Programmable, °F/°C,
1-Stage Heat, 1-Stage Cool
TSTATBBBAC01-B
Outdoor Air Temperature Sensor TSTATXXSEN01-B
Backplate for Non-Programmable Thermostat TSTATXXNBP01
Backplate for Programmable Thermostat TSTATXXPBP01
Backplate for Builder’s Thermostat TSTATXXBBP01
Thermostat Conversion Kit (4 to 5 wire) TSTATXXCNV10
