Service
If you require assistance with the installation or operation
of your Brewer Model 7000 table, call the Brewer Cus-
tomer Service Department at 1-800-558-8777. Our trained
staff will attempt to assist you in correcting the problem
directly over the phone. If service is required, a factory
authorized technician will be sent to your location.
Please fill in the following information for use when calling
the Brewer Company or your distributor with questions
regarding your unit. See Figure 1 for model and serial
number location.
Date of Purchase
Serial Number
Model Number
Authorized
Dealer Name
Dealer
Phone Number
Dealer Address
IMPORTANT INFORMATION
General
The ASSIST Powered Medical Examination Table
Model 7000 is designed to provide positioning and sup-
port of patients during general examinations conducted
by qualified medical professionals. Read and understand
all operating instructions, safety information, and main-
tenance requirements contained in this manual prior to
operating the table. Become familiar with all of the table
functions before using it with a patient.
The power examination table is primarily used in exami-
nation rooms for general examinations and minor pro-
cedures. The wide variety of positions provided by four
powered motions, adjustable legrest, adjustable headrest,
stirrups and treatment pan, create a safe and convenient
patient positioning table for most examinations and proce-
dures performed in the doctor’s office.
The table is easily adjusted to a wide variety of positions
using the convenient foot control provided with the table.
An optional hand pendant may be purchased which can
be used in conjunction with the foot control. The table
height can be adjusted from 19” to 40”. The table seating
surface can be moved from the normal horizontal position
to an angle of 30°. The backrest can be adjusted from a
flat lying down position, to an 85° angle for seating. The
legrest can be adjusted from a vertical position for seat-
ing, to a horizontal position for laying.
In addition to the electronically controlled positions noted
above, several manual adjustments are available:
1. The legrest can be manually adjusted from a sitting to
a kneeling position.
2. With the table in the horizontal position, the legrest
can be extended an additional 5” of travel for tall
patients.
3. Stirrups may be manually extended and positioned
infinitely within the lateral range of travel.
4. A removable treatment pan is built-in underneath the
front of the seat for easy access and may be pulled
out for use during examinations.
5. The headrest is multi-adjustable using three clamp
action locking levers.
6. The backrest incorporates a self-storing paper roll.
The table is designed to accommodate a maximum
patient weight of 450 lbs.
Figure 1. Model and Serial Number Location
Model & Serial Number
