—3—
Model number nomenclature
601A 024
Model No.
601A – Single Packaged
Heat Pump
Nominal Cooling Capacity (Tons)
018
– 1-1/2
024 – 2
030 – 2-1/2
036 – 3
042 – 3-1/2
048 – 4
060 – 5
ARI* CAPACITIES
COOLING CAPACITIES AND EFFICIENCIES
UNIT 601A NOMINAL TONS STANDARD CFM
NET COOLING
CAPACITIES (Btuh)
SEER†
SOUND RATINGS**
(dB)
018 1-1/2 700 19,000 10 73
024 2 800 24,000 10 73
030 2-1/2 1000 29,000 10 75
036 3 1200 35,000 10 79
042 3-1/2 1250 42,000 10 73
048 4 1600 47,000 10 80
060 5 2000 57,500 10 78
LEGEND
dB — Decibels
db — Dry Bulb
SEER — Seasonal Energy Efficiency Ratio
wb — Wet Bulb
* Air Conditioning & Refrigeration Institute.
† Rated in accordance with U.S. Government DOE (Department of
Energy) test procedures and/or ARI Standard 210/240-89.
** Tested in accordance with ARI Standard 270-95 (not listed in ARI).
NOTES:
1. Ratings are net values, reflecting the effects of circulating fan heat.
Ratings are based on:
Cooling Standard: 80°F db, 67°F wb indoor entering-air tempera-
ture and 95°F db outdoor entering-air temperature.
2. Before purchasing this appliance, read important energy cost and
efficiency information available from your retailer.
N 0 1 AD
Options
(None)
– Wire Grille
AD – Louvered Grille
BT – Wire Grille and Vinyl-Coated Condenser
Coil Fin
XT – Louvered Grille and Vinyl-Coated Con-
denser Coil Fin
CC – Wire Grille, AL Evaporator and CU/CU
Condenser Coil
AC – Louvered Grille, AL Evaporator and CU/
CU condenser Coil
AU – Louvered Grille, CU/CU Evaporator and
Condenser Coils
Packaging
Series
V-Ph-Hz
N
– 208/230-1-60
P – 208/230-3-60
E – 460-3-60
TT
Options
- -
– Wire Grille
AD – Louvered Grille
BT – Wire Grille and vinyl-coated
outdoor coil fin
XT – Louvered Grille and vinyl-coated
outdoor coil fin
CC – Wire Grille, AL indoor and CU/CU
outdoor coil
CU – Wire Grille, CU/CU indoor and
outdoor coils
AC – Louvered Grille, AL indoor and
CU/CU outdoor coil
AU – Louvered Grille, CU/CU indoor and
outdoor coils
AL — Aluminum
CU — Copper
ARI* CAPACITIES
HEATING CAPACITIES AND EFFICIENCIES
UNIT 601A
HIGH HEAT CAPACITY
(BTUH) @ 47°F
HIGH HEAT COP
@ 47°F
LOW HEAT CAPACITY
(BTUH) @ 17°F
LOW HEAT COP
@ 17°F
HSPF
018 17,600 2.9 8,600 1.8 6.6
024 23,600 2.9 12,400 1.9 6.8
030 29,000 3 15,000 1.9 6.9
036 35,000 3 18,000 1.9 7
042 40,500 3 22,000 1.9 7
048 47,000 3 27,000 2 7
060 57,000 3.2 32,000 2 7
