Label outlet maintenance 34
Introduc
tion
Cre
a
tin
g La
be
ls
4
Remove the backing paper and insert the edge of cleaning sheet into the printing
unit until the area pointed with arrow in the diagram below.
5
Close the DK Roll compartment cover and press the ON/OFF button ( ) to turn the
Brother QL-570 on.
6
Press the Feed button for more than one second.
The roller spins by 4" (10 cm).
The adhesive face of cleaning sheet removes the stain or
dust on the roller.
Label outlet maintenance
When the glue is attached on the label outlet and the machine jam a
label, pull out the power plug from the outlet and clean it up with cloth
dipped into ethanol or isopropyl alcohol.
• Insert the sheet without removing the part of sheet.
• Check that the printing surface of cleaning sheet is upward.
• If not pressing the Feed button for more than one second,
the roller spins only 1/3" (8 mm).
• Dispose the cleaning sheet after use.
Feed button
Label outlet
