Bowflex RevolutionXP - Manual (Page 5)

5
4
1
5 2
7
3
6 9
8
Hardware
Hardware Card (Box 4)
ITEM NO. QTY. DESCRIPTION
1 6 BUTTON HEAD CAP SCREW 3/8”x 4”
2 8 NARROW WASHER 5/16”
3 18 NARROW WASHER 3/8”
4 6 NYLOCK NUT 3/8”
5 8 BUTTON HEAD CAP SCREW WITH THREADLOCK 5/16”x 1”
6 1 SEAT BOTTOM LOCK PIN
7 6 BUTTON HEAD CAP SCREW WITH THREADLOCK 3/8”x 3/4”
8 1 LEG EXTENSION PIN
9 4 END CAP
