Assembly (unboxing), Step 8, Step 9 – Bowflex RevolutionXP User Manual

Page 15

Step 8

8-1 Lift the box up and off of the styrofoam packing.

8-2 Separate the styrofoam packing. Remove plastic

wrapping from the engine.

Lift box

Styrofoam packing

Separate styrofoam

packing

Step 9

Tools:
• 5/16” Allen Wrench

9-1 Install one 1/2”x3/4” Allen Bolt.

9-2 Make sure Platform is flat and level and

completely tighten hardware from steps 5
through 9.

Hardware (1:1):

1 Button Head Cap Screw With Threadlock (1/2” X 1 ”)

1 Washer (1/2”)

1/2”x 1” Allen Bolt

1/2” Washer

Assembly (Unboxing)
