Carton components may differ from one country to another.
Save all packing materials and the carton.
Carton Components
Quick Setup Guide
CD-ROM
User’s Guide
Output Paper Support Paper Tray
Ink Cartridges
(Black, Cyan, Yellow, Magenta)
Power Cord USB Cable
■ You must use the appropriate USB cable.
■ Use only a USB interface cable that is no longer than 2 meters.
Control Panel
1 . Photo Capture Centre and
On/Off keys
2 . Liquid Crystal Display (LCD) 4 . Numeric keys
3 . Navigation keys 5 . Scan and Copy keys
For the details of the control panel, see "DCP-4020C control panel overview" in Chapter 1 of the
User’s Guide.
1
3
4
1. Control Panel
2. Scanner Cover Release Lever
2
3. Scanner Cover
4. Document Cover
1 2 3 4 5
■
Getting Started
