Max Masters: Defines the highest MS/TP Master MAC
address on this MS/TP network. For example, if there are
3 master nodes on an MS/TP network, and their MAC
addresses are 1, 8, and 16, then Max Masters would be set
to 16 (since this is the highest MS/TP MAC address on
the network). This property optimizes MS/TP network
communications by preventing token passes and “poll for
master” requests to non--existent Master nodes (i.e., in
the above example, MAC address 16 would know to pass
the token back to MAC address 1 instead of counting up
to MAC address 127). Each MS/TP master node on the
network must have their Max Masters set to this same
value. The default is 127.
S
MaxInfo Frames: This property defines the maximum
number of responses that will be sent when our controller
gets the token. A valid number is any positive integer.
The default is 10 and should be ideal for the majority of
applications. In cases where the controller is the target of
many requests, this number could be increased as high as
100 or 200.
NOTE: MS/TP networks can be comprised of both Master
and Slave nodes. Valid MAC addresses for Master nodes are
0 -- 127 and valid addresses for Slave nodes are 0 -- 254.
NOTE: See RTU--MP 3rd Party Integration Guide for
Protocol Maps.
Device Instance: 0160001
1 PRGs loaded. 1 PRGs running.
Module status:
Firmware sections validated in flash memory
============================================
Boot16-H - v2.06:001 Jun 19 2007
RTU-MP DRIVER - v2.09:050 Jun 26 2007
Reset counters:
11 Power failures
0 Brownouts
18 Commanded warm boots
22 Commanded cold boots
0 System errors
0 Watchdog timeouts
System error message history: Type Specific
Warning message history:
Information message history:
POWERUP: BACnet reinitialize warmstart 06/29/07 10:49:40
Menu file not found. 06/29/07 10:48:35
ARC156 reconfigurations during the last hour (cleared upon reset):
Total ....................... 0
Initiated by this node ...... 0
Core board hardware:
Type=147, board=34, manufactured on 05/14/2007, S/N 21A740188N
RAM: 1024 kBytes; FLASH: 1024 kBytes, type = 3
Base board hardware:
Type=147, board=71, manufactured on 05/14/2007, S/N RMP750037N
Largest free heap space = 65536.
Database size = 742082 , used = 352162, free = 389920.
Raw physical switches: 0x01280000
Module Communications:
Network Protocol=BACnet MSTP Master
Network Baud Rate=9600 bps
C07195
Fig. 65 -- Module Status Report (Modstat) Example
