77
APPENDIX III. FAN PERFORMANCE (cont.)
Table 35 – 548J*06A 5 TON HORIZONTAL SUPPLY
CFM
AVAILABLE EXTERNAL STATIC PRESSURE (IN. WG)
0.2 0.4 0.6 0.8 1.0
RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP
1500 725 0.33 840 0.46 937 0.60 1023 0.75 1101 0.90
1625 765 0.40 876 0.54 970 0.68 1054 0.84 1131 1.00
1750 806 0.48 912 0.63 1004 0.78 1087 0.94 1162 1.11
1875 847 0.57 950 0.72 1039 0.88 1120 1.05 1194 1.23
2000 889 0.66 988 0.83 1075 1.00 1154 1.18 1226 1.36
2125 931 0.78 1027 0.95 1112 1.13 1189 1.31 1260 1.50
2250 974 0.90 1067 1.08 1149 1.27 1224 1.46 1294 1.66
2375 1018 1.03 1107 1.23 1187 1.43 1261 1.63 1329 1.84
2500 1061 1.19 1148 1.39 1226 1.59 1297 1.81 1364 2.02
Med static
High static
CFM
AVAILABLE EXTERNAL STATIC PRESSURE (IN. WG)
1.2 1.4 1.6 1.8 2.0
RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP
1500 1172 1.06 1239 1.23 1302 1.40 1361 1.58 1418 1.77
1625 1201 1.16 1267 1.34 1329 1.52 1388 1.71 1444 1.90
1750 1231 1.28 1296 1.46 1358 1.65 1416 1.84 1472 2.04
1875 1262 1.41 1326 1.60 1387 1.79 1445 1.99 1499 2.20
2000 1294 1.55 1357 1.74 1417 1.95 1474 2.15 1528 2.36
2125 1326 1.70 1388 1.90 1447 2.11 1504 2.33 1557 2.55
2250 1359 1.87 1420 2.08 1479 2.29 1534 2.51 1587 2.74
2375 1393 2.05 1453 2.27 1511 2.49 1566 2.72 1618 2.95
2500 1427 2.24 1487 2.47 1543 2.70 1597 2.94 1649 3.18
Med static
High static
Table 36 – 548J*06A 5 TON VERTICAL SUPPLY
CFM
AVAILABLE EXTERNAL STATIC PRESSURE (IN. WG)
0.2 0.4 0.6 0.8 1.0
RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP
1500 794 0.41 902 0.55 993 0.69 1074 0.85 1147 1.00
1625 840 0.49 945 0.64 1034 0.80 1113 0.96 1185 1.13
1750 888 0.59 988 0.75 1075 0.92 1153 1.09 1223 1.26
1875 936 0.70 1033 0.87 1117 1.05 1193 1.23 1263 1.41
2000 984 0.82 1078 1.00 1160 1.19 1235 1.39 1303 1.58
2125 1033 0.96 1124 1.15 1204 1.35 1277 1.56 1343 1.76
2250 1083 1.11 1170 1.32 1248 1.53 1319 1.74 1385 1.96
2375 1133 1.28 1217 1.50 1293 1.72 1363 1.95 1427 2.17
2500 1183 1.47 1265 1.70 1339 1.93 1406 2.17 1470 2.41
Med static
High static
CFM
AVAILABLE EXTERNAL STATIC PRESSURE (IN. WG)
1.2 1.4 1.6 1.8 2.0
RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP
1500 1214 1.16 1277 1.33 1336 1.50 1392 1.67 1445 1.85
1625 1251 1.30 1313 1.47 1371 1.65 1427 1.83 1479 2.02
1750 1289 1.44 1350 1.63 1407 1.81 1462 2.01 1514 2.20
1875 1327 1.60 1387 1.80 1444 1.99 1498 2.19 1550 2.40
2000 1366 1.78 1426 1.98 1482 2.19 1535 2.40 1586 2.61
2125 1406 1.97 1464 2.18 1520 2.40 1573 2.62 1623 2.84
2250 1446 2.18 1504 2.40 1559 2.62 1611 2.85 1661 3.09
2375 1487 2.40 1544 2.63 1598 2.87 1650 3.11 --- ---
2500 1529 2.64 1585 2.89 1638 3.13 --- --- --- ---
Med static
High static
548J
