6.6 Specifications
Analog Inputs
Connectors XLR and 1/4" jack
Type RF filtered, servo balanced input
Impedance 60 kOhms balanced, 30 kOhms unbalanced
Nominal Operating Level -10dBV to +4dBu
Max. Input Level +16 dBu at +4 dB nominal level, +2 dBV at -10 dBV nominal level
Analog Outputs
Connectors XLR and 1/4" jack
Type Electronically servo-balanced output stage
Impedance 60 Ohms balanced, 30 Ohms unbalanced
Max. Output Level +16 dBu at +4 dB nominal level, +2 dBV at -10 dBV nominal level
System specifications
Bandwidth 20 Hz to 20 kHz, +0/-3 dB
Noise >94 dBu, unweighted, 20 Hz to 20 kHz
THD 0.0075 % typ. @ +4 dBu, 1 kHz, Gain 1
Crosstalk < -76 dBu
MIDI Interface
Type 5-Pin-DIN-Socket IN / OUT / THRU
Digital Processing
Converters 20-bit Sigma-Delta, 64/128-times Oversampling
Sampling Rate 46,875 kHz
Display
Type 2 ½-digit numeric LED-Display
Power Supply
Mains Voltages USA/Canada ~ 120 V AC, 60 Hz
U.K./Australia ~ 240 V AC, 50 Hz
Europe ~ 230 V AC, 50 Hz
General Export Model ~ 100-120 V AC, ~ 200-240 V AC, 50-60 Hz
Fuse 100-120 V AC: 125 mA (slow-blow)
200-240 V AC: 63 mA (slow-blow)
Power Consumption 10 Watts
Mains Connection Standard IEC receptacle
Physical
Dimensions (H * W * D) 1 3/4” (44.5 mm) * 19” (482.6 mm) * 7 1/2” (190.5 mm)
Net Weight ± 2 kg
Shipping Weight ± 3 kg
BEHRINGER is constantly striving to maintain the highest professional standards. As a result of these efforts, modifications may be made from time
to time to existing products without prior notice. Specifications and appearance may differ from those listed or shown.
