Page 7

7
Form 6104 BCF14N-R0299
Instruction Manual – Model CF1400 Oil Burner
Figure 5 - Nozzle line assembly in burner
Z
1408
a
Measure dimension
from
front (flat) face of head to
end of air tube, as shown.
Z
b
c
d
Measure dimension Z from the flat
surface between (not on) the raised fins.
1424
Figure 7 - Burner installed in appliance front
1403
D
H
K
J
a
b
c
Legend
H Housing total length —
18
"
J Center to bottom of housing —
10
⁷⁄₈
⁷⁄₈
⁷⁄₈
⁷⁄₈
⁷⁄₈
"
K Overall housing height —
13
³⁄₈
³⁄₈
³⁄₈
³⁄₈
³⁄₈
"
❏ Set dimension Z
• Replace the rear access door on the
burner, making sure that the adjust-
ing plate assembly is now securely
held in place.
• Loosen acorn nut
d
in
Figure 5
.
Slide the nozzle line and plate as-
sembly until dimension
Z
in
Figure 5
is
1³⁄₄
1³⁄₄
1³⁄₄
1³⁄₄
1³⁄₄" ± ¹⁄₁₆
¹⁄₁₆
¹⁄₁₆
¹⁄₁₆
¹⁄₁₆". When di-
mension
Z
(from end of air tube to
flat area of front face of head) is cor-
rectly set, tighten acorn nut
d
. Verify
that the adjusting plate assembly is
properly seated at the rear access
door, as shown in
Figure 5
.
• Attach the oil line from the oil valve
to the nozzle line end. Tighten se-
curely.
• Before proceeding, check dimen-
sion
Z
once again. Loosen acorn nut
d
if necessary to reposition the
nozzle line. Once dimension
Z
is set,
do not loosen acorn nut
d
again.
For the setting of acorn nut
c
, refer
to page 12.
Figure 6 - Adjusting plate assy.
1408-1
e
f
g
c
d
Legend (Figures 5 and 6)
a Adjusting plate assembly
b Spline nut for securing nozzle line
c Bottom acorn nut
d Top acorn nut (for setting dim. Z
only)
e Indicator adjusting plate
f
Secondary adjusting plate
g Primary adjusting plate
❏ Insert burner
• Position the burner in the front of
the appliance and loosely tighten
the nuts on the mounting studs. The
burner should be pitched downward
2° as shown in
Figures 3
and
7
.
• See
Figure 7
. Install the pedestal
support kit (recommended) by at-
taching the ¾" npt flange (item
a
)
to the bottom of the burner using
the (
4
) #10 screws provided. Cut and
thread (one end only) a ¾" pipe
nipple (item
b
) with length 11
inches less than dimension
D
in
Fig-
ure 7
. Thread the pipe into the
flange. Then slip the pipe end into
the floor flange (item
c
).
• Secure the burner to the appliance
by tightening the nuts on the burner
flange mounting studs. Then secure
the pedestal support floor flange set
screw to the pipe.
