LTM 1500-8.1
• Modular set-up of the counterweight frame, consisting of
base frame and two winch packages, compact transport unit
• Winch 2 and winch 3 with luffing block are pinned and thus
quickly interchangeable if required, e.g. for the application
of a second LTM 1500-8.1
• The winches are connected to the hydraulic system of the
crane by rapid action couplings
• Auxiliary winch with control panel for reeving of the hoist
rope and luffing rope
Counterweight frame – compact
and quickly mountable
2480
5200
R = 6600
