Load chart for duty cycle operation, 9 t counterweight – Liebherr HS 8030 HD Litronic User Manual
Page 8
8
HS 8030 HD
Above load chart is for reference only.
For actual lift duty please refer to load chart in operator’s cab or manual.
Capacities in metric tonnes for boom lengths (10 m - 22 m) - with 100 kN winches
Boom length (m)
Radius
10
13
16
19
22
(m)
t
t
t
t
t
2
14.9
14.9
14.9
3
14.0
14.9
13.2
12.7
11.3
4
12.0
11.3
10.1
9.5
8.4
5
9.1
8.5
8.1
7.6
6.8
6
7.4
7.1
6.7
6.3
5.7
7
6.3
6.0
5.7
5.3
4.8
8
5.5
5.2
4.9
4.6
4.2
9
4.8
4.5
4.3
4.0
3.7
10
3.9
3.8
3.5
3.2
Maximum capacity in duty cycle operation with standard ropes
Line pull
kN
100
Rope diameter
mm
24
Minimum breaking load
kN
355
Line pull - 1-rope duty cycle operation
t
10
Line pull - 2-rope duty cycle operation
1)
t
15.2
1) Lifting a load exceeding the line pull of one winch is only allowed
if it can be ensured that each individual winch is not overloaded.
When working with a mechanical 2-rope grab the total load
to be lifted is limited by the line pull of one winch.
Rigging and ropes are part of the load.
2) Max. capacities in metric tonnes do not exceed 75% of
tipping load. Crane standing on firm, horizontal ground.
Capacities in duty cycle operation are for reference only and are not programmed in the LMI system.
All loads and counterweight configurations are max. values and must not be exceeded.
Weight of additional equipment on boom (e.g. walkways, hose drums etc.) must be deducted to get the net capacity.
Load chart for duty cycle operation
(Main boom No. 0808.xx)
5.9 t counterweight
