10 HS 8030 HD
0 m 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22
0 ft 5 10 15 20 25 30 35 40 45 50 55 60 65 70
70°
84°
80°
60°
50°
40°
30°
10 m
13 m
16 m
0 0
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
5
15
20
25
30
35
40
45
50
55
60
65
70
75
80
85
10
22 m
19 m
Main boom
(No. 0808.xx)
84° – 30°
5.9 t counterweight
Main boom configuration
(No. 0808.xx)
Configuration for boom lengths (10 m - 22 m)
Length Amount of boom extensions
Boom foot 6.0 m 1 1 1 1 1
Hinged section 0.5 m 1 1 1 1 1
Boom section 3.0 m 1 2 3 4
Boom head 3.5 m 1 1 1 1 1
Boom length (m) 10 13 16 19 22
