HS 8030 HD 11
Load chart for lift crane operation
(Main boom No. 0808.xx)
5.9 t counterweight
Above load chart is for reference only.
For actual lift duty please refer to load chart in operator’s cab or manual.
Capacities in metric tonnes for boom lengths (10 m - 22 m) - with 100 kN winches
Boom length (m)
Radius 10 13 16 19 22
(m) t t t t t
2 29.4 29.3 29.1 29.0
3 28.5 28.5 24.2 22.0 19.6
4 22.3 20.9 19.4 17.1 15.6
5 16.4 15.6 14.9 14.1 12.8
6 12.5 12.3 11.8 11.3 10.8
7 9.7 9.9 9.7 9.3 8.9
8 7.8 8.0 8.1 7.8 7.5
9 6.4 6.6 6.7 6.6 6.3
10 5.5 5.6 5.6 5.5
12 4.0 4.1 4.1 4.1
14 3.0 3.0 3.0
16 2.3 2.2
