GUIDE SPECIFICATIONS
Plus 90x
Single--Stage/Deluxe Gas Furnace
353AAV
GENERAL
System Description
Furnish a _________________ (4--way multipoise) fixed
capacity gas--fired condensing furnace for use with natural gas or
propane (factory authorized conversion kit required for propane);
furnish cold air return plenum; furnish external medial cabinet for
use with accessory media filter or standard filter.
Quality Assurance
Unit will be designed, tested and constructed to the current ANSI
Z 21.47/CSA 2.3 design standard for gas--fired central furnaces.
Unit will be 3rd party certified by CSA to the current ANSI Z
21.47/CSA 2.3 design standard for gas--fired central furnaces.
Unit will carry the CSA Blue Star® and Blue Flame® labels.
Unit efficiency testing will be performed per the current DOE test
procedure as listed in the Federal Register.
Unit will be certified for capacity and efficiency and listed in the
latest GAMA Consumer’s Directory of Certified Efficiency
Ratings.
Unit will carry the current Federal Trade Commission Energy
Guide efficiency label.
Delivery, Storage and Handling
Unit will be shipped as single package only and is stored and
handled per unit manufacturer’s recommendation.
Warranty (for inclusion by specifying engineer)
U.S. and Canada only. Warranty certificate available upon
request.
PRODUCTS
Equipment
Components shall include: slow--opening gas valve to reduce
ignition noise, regulate gas flow, with electric switch gas
shut--off; flame proving sensor, hot surface igniter, pressure
switch assembly verifies inducer operation; flame rollout switch,
drain tubing and installed condensate drain trap, blower and
inducer assembly, 40va transformer; low--voltage (heating)
(heating/ cooling) thermostat.
Blower Wheel and Blower Motor
Galvanized blower wheel shall be centrifugal type, statically and
dynamically balanced. Blower motor of ECM type shall be
permanently lubricated with sealed bearings, of _____ hp, and
shall be multiple--speed direct drive. Blower motor shall be soft
mounted to the blower scroll to reduce vibration transmission.
Filters
Furnace shall have reusable--type filters. Filter shall be ______ in
(x) ______in. An accessory high efficiency Media Filter is
available as an option. ______________Media Filter.
Casing
Casing shall be of .030 in. (.03 mm) thickness minimum,
pre--painted galvanized steel.
Inducer Motor
Inducer motor shall be soft mounted to reduce vibration
transmission.
Primary Heat Exchangers
Primary Heat exchangers shall be 3--Pass 20 gauge corrosion
resistant aluminized steel of fold--and--crimp sectional design,
which operates under negative pressure.
Secondary Heat Exchangers
Secondary Heat exchangers shall be of a flow--through design
having a patented interior laminate coating of polypropylene for
greater corrosion resistance with fold--and--crimp design, which
operates under negative pressure.
Controls
Controls shall include a microprocessor based integrated
electronic control board with at least 11 service troubleshooting
codes displayed via diagnostic flashing LED light on the control,
has ability to store fault codes, when activated a self--test feature
checks all major functions of the furnace within one minute, and
a replaceable automotive--type circuit protection fuse. Multiple
operational settings available including separate blower speeds.
Cooling airflow will be selectable between 350 or 400 CFM per
ton of air conditioning. Features will also include temporary
reduced airflow in the cooling mode for improved
dehumidification when a Thermidistat® is selected as the
thermostat.
Operating Characteristics
Heating Capacity shall be_________Btuh
input;____________Btuh output capacity. Fuel Gas Efficiency
shall be 93% AFUE. Air delivery shall be__________ CFM
minimum at 0.50 in. wc. external static pressure. Dimensions
shall be: depth__________in.; width__________in.; height
_________in. (casing only). Height shall be__________in. with
A/C coil and____________in. overall with plenum.
Electrical Requirements
Electrical supply shall be 115 volts, 60 Hz, single--phase
(nominal). Minimum wire size shall be_________AWG;
maximum fuse size or HACR--type, designated circuit breaker
shall be _______Amps.
Special Features
Refer to section of the product data sheet identifying accessories
and descriptions for specific features and available enhancements.
