Typical installations (continued) – Bryant PLUS 90X 353AAV User Manual
Page 21
21
TYPICAL INSTALLATIONS (CONTINUED)
COMBUSTION–AIR PIPE
ELECTRONIC
AIR CLEANER
FURNACE
CONDENSATE
DRAIN
REFRIGERATION
PIPING
AIR CONDITIONING
COIL
AIRFLOW
VENT PIPE
FRONT OF FURNACE
DIRECT VENT/2-PIPE APPLICATION)
COMBUSTION-AIR INLET
(NON-DIRECT VENT/1-PIPE APPLICATION)
A05066
Attic -- Horizontal Application
COMBUSTION– AIR PIPE
(DIRECT VENT/2-PIPE
APPLICATION)
VENT
PIPE
ELECTRONIC
AIR CLEANER
FURNACE CONDENSATE
DRAIN
AIR CONDITIONING
COIL
REFRIGERATION
PIPING
FRONT OF
FURNACE
COMBUSTION - AIR INLET
(NON-DIRECT VENT/
1-PIPE APPLICATION)
A08422
Crawlspace -- Horizontal Application
353AA
V
