Application settings
Nio® medical display systems 97
Figure 50: Dual-head equalization
The reference display is the first calibrated display in the system.
The Equalization option will be available only if:
• the system contains at least one display of the same type as
the one being calibrated
• at least one of the displays of the same type has already
been calibrated before using a sensor.
MediCal Administrator tab
Figure 51: MediCal Administrator tab
Here you can connect to MediCal Administrator, if present.
To connect to MediCal Administrator, click the MediCal
Administrator button. As a result, the MediCal Administrator
BARCO BARCO
c "
(1) Reference display
(2) Calibrated display: Luminance automatically matched
to reference display
