Technical specifications
Nio® medical display systems 129
Technical specifications
E- 2620:
Item Specification
Picture panel 19.6-inch diagonal viewable screen TFT
(thin film transistor) active matrix, gray-
scale liquid crystal display
Resolution Native: 1600 x 1200
Display area (H x V) 398.4 x 298.8 (mm)
Viewing angle
(@ 10/1 contrast) Vertical: 170º
Horizontal: 170º
Pixel Pitch 0.249 mm (H) x 0.249 mm (V)
Native color resolution 8 bits / sub-pixel
Luminance 500 cd/m² (calibrated)
Contrast ratio 850/1 (on/off in dark environment)
Response time 20 ms typical (@ 25° C after 30 min
warm-up)
Controls Push / turn control wheel for stand-by
switching and OSD controls
Input connectors DVI dual channel
Signal systems Video on DVI: Complying to DVI Rev 1.0
specifications
Sync on DVI: Complying to DVI Rev 1.0
specifications
Input signals Possible resolutions:
• 640 x 480 @ 60, 75, 85, 100 Hz
• 1600 x 1200 @ 59, 60 Hz
• 1200 x 1600 @ 59 Hz
USB standard supported USB 1.1
