Display installation
Nio® medical display systems 37
Adjust the panel orientation
You can change the orientation of the panel at any time, but it is
more convenient to select landscape or portrait orientation
before connecting the cables.
To change the panel orientation:
1. Stand at the front side of the panel and take the panel at
both sides.
2. Very important: Tilt the panel before changing the
orientation.
Should you change the panel orientation without tilting it
first, you might irreversibly damage the tilt & swivel
mechanism.
Figure 8:
Portrait
orientation
Figure 9:
Landscape
orientation
