4. Getting started
4.5 Quick set up adjustments
Overview
• Quick lens Adjustment
• Using the RCU
• Projector address
• Controlling the projector
• Using the menu
• Using the Dialogboxes
4.5.1 Quick lens Adjustment
What can be done ?
For a quick lens set up and image shift, use the RCU dedicated keys.
Zoom/focus are only available for motorized lenses.
Quick zoom/focus adjustment
1. Press LENS ZOOM or
LENS FOCUS on the RCU
2. Use the arrow keys to adjust
Quick shift adjustment
1. Press LENS SHIFT
2. Press ← or → to shift horizontaly
3. Press ↓or ↑ to shift verticaly
4.5.2 Using the RCU
Pointing to the reflective screen
1. Point the front of the RCU to the reflective screen surface. (image 4-4)
R5976455 BARCO ULTRA REALITY 7000 30062003 25
