4. Getting started
Image 4-1
1 Function keys user programmable keys with functions for direct access.
2 MENU Menu key, to enter or exit the Toolbar menu.
3 Address key (recessed key), to enter the address of the projector (between 0 and 9). Press the recessed
address key with a pencil, followed by pressing one digit button between 0 and 9.
4 LOGO key allows to recall the stored Logo (not in PiP mode)
5 PAUSE to stop projection for a short time, press ’PAUSE’. The image disappears but full power is
retained for immediate restarting.
6 STBY standby button, to start projector when the power switch is switched on and to switch off the
projector without switching off the power switch.
Attention : Switching to Standby. When the projector is running and you want to
go to standby, press the standby key for 2 seconds.
7 MUTE not used
8 AUTOIMAGE Auto image, to center the image on the active LCD surface.
9 Digit buttons direct input selection.
9b SOURCE button this button allows to switch through the active (scanned) inputs
10 Lens control use these buttons to obtain the desired ZOOM, SHIFT, FOCUS.
11 VOL not used
12 Picture controls use these buttons to obtain the desired picture analog level.
