3. OVERVIEW USER’s CONTROLS
Factory address setting of the modules
The factory address setting of the modules is as follows:
Module Individual Address Common Address
Cine VERSUM 80 address <9> no common address
Cine VERSUM 50 address <9> no common address
Cine VERSUM Master address <1> common address <0>
Common address: is a fixed address, stored in the module. The module will execute the commands sent by
a Remote Control, programmed with the common address <0>.
3.5.2 Battery Insertion in the Remote Control
Where to find the batteries
The batteries are not placed in the remote control to avoid remote control operation in its package, resulting in a shorter battery life
time.
How to install the batteries
1. Push the cover tab (A) with the fingernail a little backwards and pull upwards the cover top (B). (image 3-6)
2. Slide the cover forwards to remove. (image 3-7)
3. Push the battery body towards the spring and lift it up to remove. (image 3-8)
4. Insert two AA size batteries, making sure the polarities match the + and – marks inside the battery compartment (image 3-8).
5. Insert the lower tab of the battery cover in the gap at the bottom of the remote control, and press the cover until it clicks in place
(image 3-8).
Image 3-6
Battery cover unlock
Image 3-7
Battery cover removal
Image 3-8
Battery removal
12 R5976490 CINE VERSUM SYSTEM 17012003
