3. OVERVIEW USER’s CONTROLS
Image 3-4
Remote Control
Controls function description
Ref.
Function
Description
1
Address button
To match the Remote Control with the unit that you are addressing (number between
0 and 9).
2
Standby button
To power up/down the Cine VERSUM Master and the displays in the link.
3
Digit buttons
Allows to directly select sources.
4
RC operation indication
Lights up when a button on the remote control is pressed (Visual indication of remote
control operation – Battery check).
5
TEXT
Press to remove bar scale display when adjusting picture. Press button again for
reactivation.
6
FREEZE
Press to freeze the image
7
Picture controls
Allow to optimize the picture reproduction
Table 3-4
Stored sources
The Cine VERSUM Master can be equipped with up to 8 digital and analog input modules. These modules are linked to your sources
and can be selected with the touch of a button on the Remote Control.
The table below allows you to note the stored source per input slot, digit button 1 to 8.
Digit Button
Stored source
1
2
3
10
