18

Coronis Fusion 4MP/6MP

Re-attaching the covers

1

Re-attach the display stand cover by sliding it downward. You’ll
hear a “click” sound of the cover’s clips when the display stand
cover is in position.

2

Re-attach the connector compartment cover by sliding the cover’s
top in position and then push the cover’s bottom. You’ll hear a
“click” sound of the cover’s clips when the connector compartment
cover is in position.

Pay attention that all cables stay in the cable channel
while replacing the cover.
