Fig. 4 — Roof Curb Dimensions
ROOF CURB
ACCESSORY
‘‘A’’ UNIT SIZE
CRRFCURB001A00
14 Љ
[356]
581B036-072
CRRFCURB002A00
24 Љ
[610]
NOTES:
1. Roof
curb accessory is shipped
disassembled.
2. Insulated panels.
3. Dimensions in [
] are in millimeters.
4. Roof curb: galvanized steel.
5. Attach ductwork to curb (flanges of duct
rest on curb).
6. Service clearance 4 ft on each side.
7. Direction of airflow.
UNIT
581B
SERVICE PLATE SIZES
CONNECTOR
PACKAGE
ACCESSORY
‘‘B’’ ‘‘C’’
‘‘D’’ Alt
Drain
Hole
‘‘E’’
Gas
‘‘F’’
Power
‘‘G’’
Control
036-072
21 11 ⁄ 16
Љ
[551]
16 Љ
[406]
1 3 ⁄ 4
Љ
[44.5]
3 ⁄
4
Љ NPT 3 ⁄
4
Љ NPT 3 ⁄
4
Љ NPT
314213-204
(Thru-the-Side)
3 ⁄ 4
Љ NPT 3 ⁄ 4
Љ NPT 1 ⁄ 2
Љ NPT
CRBTMPWR001A00
(Thru-the-Bottom)
