High-Voltage Connections (Fig. 13)

The unit must have a separate electrical service with a field-
supplied, waterproof, fused disconnect switch mounted at, or
within sight from the unit. Refer to the unit rating plate for
maximum fuse/circuit breaker size and minimum circuit amps
(ampacity) for wire sizing.

The field-supplied disconnect switch box may be mounted on
the unit over the high-voltage inlet hole in the control corner
panel.

Proceed as follows to complete the high-voltage connections
to the unit:

1. Connect ground lead to chassis ground connection when

using separate ground wire.

2. Pigtails are provided for field power connection.

Use factory-supplied splices or UL (Underwriters’

Laboratories) approved copper connector. Install con-
duit connectors in side panel power supply knockout
openings indicated in Fig. 2. Route power lines through
connector to unit control box.

Special Procedures for 208-V Operation

DANGER:

Make sure that the power supply to the

unit is switched OFF before making any wiring changes.
Electrical shock can cause personal injury or death.

For operation on 208 v, disconnect the black wire from the
230-v orange wire on the transformer and connect it to the
200-v red wire from the transformer. Insulate the end of the
orange wire.

Table 3A — Electrical Data (Units Without Electrical Convenience Outlet)

UNIT
581B

NOMINAL
VOLTAGE

(V-Ph-Hz)

VOLTAGE

RANGE

COMPRESSOR

OFM

IFM

COMBUSTION

FAN MOTOR

POWER SUPPLY

MINIMUM UNIT

DISCONNECT

SIZE*

Min

Max

RLA

LRA

FLA

FLA

FLA

MCA

MOCP†

FLA

LRA

036

(3 Tons)

208/230-1-60

187

254

16.0

88.0

0.7

4.9

.57

25.6/25.6

35/35

25/25

101/101

208/230-3-60

187

254

10.3

77.0

0.7

4.9

.57

18.5/18.5

25/25

18/18

90/ 90

460-3-60

414

508

5.1

39.0

0.4

2.2

.30

9.0

15

9

46

575-3-60

518

632

4.2

31.0

0.4

2.2

.30

7.3

15

7

37

048

(4 Tons)

208/230-1-60

187

254

23.7

129.0

0.7

4.9

.57

35.2/35.2

45/45

34/34

142/142

208/230-3-60

187

254

13.5

99.0

0.7

4.9

.57

22.5/22.5

30/30

22/22

112/112

460-3-60

414

508

7.4

49.5

0.4

2.2

.30

9.7

15

12

57

575-3-60

518

632

5.8

40.0

0.4

2.2

.30

9.3

15

9

46

060

(5 Tons)

208/230-1-60

187

254

28.8

169.0

1.5

8.8

.57

46.3/46.3

60/60

45/45

216/216

208/230-3-60

187

254

17.3

123.0

1.5

5.8

.57

29.0/29.0

35/35

28/28

168/168

460-3-60

414

508

9.0

62.0

0.8

2.6

.30

14.7

20

14

84

575-3-60

518

632

7.1

50.0

0.8

2.6

.30

11.6

15

11

59

072

(6 Tons)

208/230-3-60

187

254

20.5

156.0

1.4

5.8

.57

32.8/32.8

40/40

32/32

200/200

460-3-60

414

508

9.6

70.0

0.6

2.6

.30

15.2

20

15

92

575-3-60

518

632

7.7

56.0

0.6

2.6

.30

12.2

15

12

74

LEGEND

FLA

Full Load Amps

HACR — Heating, Air Conditioning and Refrigeration
IFM

Indoor (Evaporator) Fan Motor

LRA

Locked Rotor Amps

MCA

Minimum Circuit Amps

MOCP — Maximum Overcurrent Protection
NEC

National Electrical Code

OFM

Outdoor (Condenser) Fan Motor

RLA

Rated Load Amps

UL

Underwriters’ Laboratories

*Used to determine minimum disconnect per NEC.

†Fuse or HACR circuit breaker.

NOTES:
1. In compliance with NEC requirements for multimotor and combina-

tion load equipment (refer to NEC Articles 430 and 440), the over-
current protective device for the unit shall be fuse or HACR breaker.
The CUL units may be fuse or circuit breaker.

2. Unbalanced 3-Phase Supply Voltage

Never operate a motor where a phase imbalance in supply voltage is
greater than 2%. Use the following formula to determine the percent-
age of voltage imbalance.

max voltage deviation

from average voltage

% Voltage Imbalance = 100 x

average voltage

EXAMPLE: Supply voltage is 460-3-60.

AB = 452 v
BC = 464 v
AC = 455 v

452 + 464 + 455

Average Voltage =

3

1371

=

3

= 457

Determine maximum deviation from average voltage.

(AB) 457 – 452 = 5 v
(BC) 464 – 457 = 7 v
(AC) 457 – 455 = 2 v

Maximum deviation is 7 v.
Determine percentage of voltage imbalance:

7

% Voltage Imbalance = 100 x

457

= 1.53%

This amount of phase imbalance is satisfactory as it is below the
maximum allowable 2%.
IMPORTANT: If the supply voltage phase imbalance is more than
2%, contact your local electric utility company immediately.

3. 575-v units are UL, Canada approved only.
