83 Hardware Troubleshooting
Troubleshooting the 10/100 PS
07/18/2008 BradyConnect 10/100 Internal Print Server User Guide Y885775
10/100 Internal PS Network Status/Activity Indicator
For the BBP81 (4”) and BBP81 (6”) printers
Alongside of the RJ45 connector, there is a single LED containing a red element and a green
element. By turning on and off different combinations of these two LED elements, the LED
indicates Ethernet links, activity, and speed.
LED State Description
Off No Ethernet link detected
Amber 10 Mbps link detected
Amber, blinking 10 Mbps link detected and Ethernet activity detected
Green 100 Mbps link detected
Green, blinking 100 Mbps link detected and Ethernet activity detected
