User’s Manual
3-22
Hardware, Utilities and Options
5. PORTÉGÉ R600: Loosen the two screws securing the memory module
cover in place - please note that this screw is attached to the cover in
order to prevent it from being lost.
PORTÉGÉ A600: Loosen the one screw securing the memory module
cover in place - please note that this screw is attached to the cover in
order to prevent it from being lost.
6. Slide your fingernail or a thin object under the cover and lift it off.
Removing the memory module cover (PORTÉGÉ R600)
Removing the memory module cover (PORTÉGÉ A600)
7. Align the notch of the memory module with that of the memory slot and
gently insert the module into the slot at about a 45 degree angle before
holding it down until the latches on either side snap into place.
Use a point size 0 Phillips screwdriver.
Screws
Memory
module cover
Screw
Memory
module cover
