User’s Manual
2-1
Chapter 2
The Grand Tour
This chapter identifies the various components of your computer. Become
familiar with each component before you operate the computer.
Front with the display closed
The figure below shows the computer’s front with its display panel in the
closed position.
Front of the computer with display closed
An asterisk * indicates a optional feature that is dependant on the model
purchased.
Display latch
Volume control
System Indicators
Headphones
Microphone
Display latch
This latch secures the LCD panel in its closed
position. Slide the latch to open the display.
Microphone jack
A standard 3.5 mm mini microphone jack
enables connection of a monaural microphone or
other device for audio input.
