Part names 05
11
En
English
Remote control unit
Point the remote control at the unit to operate.
1 button
Press to set power to ON/STANDBY.
2 INPUT buttons
Press to select the unit’s source INPUT 1 to INPUT 6.
3 RESOLUTION button
Use to set output resolution when converting analog
input signals to HDMI. (See page 19.)
4 COLOUR SYSTEM button
Use to set the colour system for analog input signals.
(See page 19.)
5 SIGNAL SELECT button
Use to select input signal for INPUT 3. (See page 19.)
6 VIDEO button
Use to set the colour format when converting analog
input signals to HDMI. (See page 20.)
7 AUDIO button
Use to set the type of audio signal during HDMI input.
(See page 20.)
INPUT
SETTING
RESOLUTION
COLOUR
SYSTEM
SIGNAL
SELECT
VIDEO
AUDIO
HDMI
1 2 3
4 5 6
HD AV CONVERTER
1
2
3
4
5
6
7
