Additional information 12
104
En
Specifications
• These specifications are applicable when the power
supply is 230 V.
Audio section
Rated power output (1 kHz, 6
Ω, 1 %)
Front . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 150 W + 150 W
Center . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 150 W
Surround . . . . . . . . . . . . . . . . . . . . . . . . . . . 150 W + 150 W
Surround back (Front height/wide). . . . . . 150 W + 150 W
Rated power output (20 Hz to 20 kHz, 8
Ω, 0.08 %)
Front . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 110 W + 110 W
Center . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 110 W
Surround . . . . . . . . . . . . . . . . . . . . . . . . . . . 110 W + 110 W
Surround back (Front height/wide). . . . . . 110 W + 110 W
Total Harmonic Distortion . . . . . . . . . . . . . . . . . . . . . . .0.06 %
(20 Hz to 20 kHz, 8
Ω, 100 W + 100 W)
Guaranteed speaker impedance
. . . . . . . . 16
Ω to 8 Ω, less than 8 Ω to 6 Ω (setting required)
Signal-to-Noise Ratio (IHF, short circuited, A network)
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 103 dB
Frequency Response . . . . . . . . . . . . 5 Hz to 100 000 Hz dB
(Pure Direct Mode)
Input (Sensitivity/Impedance) . . . . . . . . . . . . . . 350 mV/47 k
Ω
Output (Level/Impedance)
REC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 350 mV/2.2 k
Ω
Tuner Section
Frequency Range (FM). . . . . . . . . . . . . .87.5 MHz to 108 MHz
Antenna Input (FM) . . . . . . . . . . . . . . . . . . . 75
Ω unbalanced
Frequency Range (AM) . . . . . . . . . . . . . .531 kHz to 1602 kHz
Antenna (AM) . . . . . . . . . . . . . . . . . Loop antenna (balanced)
Video Section
Signal level
Composite Video . . . . . . . . . . . . . . . . . . . . . . .1 Vp-p (75
Ω)
Component Video. . . . . . . . . . . . . . . . . . .Y: 1.0 Vp-p (75
Ω),
PB, PR: 0.7 Vp-p (75
Ω)
Corresponding maximum resolution
Component Video. . . . . . . . . . . . . . . . . . . . . . 1080p (1125p)
(Video convert off)
Digital In/Out Section
HDMI terminal . . . . . . . . . . . . . . . . . . . . . . . . 19-pin (Not DVI)
HDMI output type . . . . . . . . . . . . . . . . . . . . . . . . . .5 V, 100 mA
USB terminal . . . . . . . . . . . . . . . USB2.0 Full Speed (Type A)
iPod terminal . . . . . . . . . . . . . . USB, and Video (Composite)
ADAPTER PORT terminal . . . . . . . . . . . . . . . . . . .5 V, 100 mA
Integrated control section
Control (SR) terminal . . . . . . . . . . . . Ø 3.5 Mini-jack (MONO)
Control (IR) terminal. . . . . . . . . . . . . Ø 3.5 Mini-jack (MONO)
IR signal . . . . . . . . . . . . . . . . . High Active (High Level: 2.0 V)
12 V Trigger terminal . . . . . . . . . . . . Ø
3.5 Mini-jack (MONO)
12 V Trigger output type . . . . . . . . . . . . . . . 12 V, Total 150 mA
RS-232C cable type. . . . . . . .9-pin, cross type, female-female
EXTENSION terminal . . . . . . . . . . . . . . . . . . . . . . .5 V, 150 mA
Network Section
LAN terminal . . . . . . . . . . . . . . . . . . .10 BASE-T/100 BASE-TX
Bluetooth ADAPTER (AS-BT100) (VSX-LX53 only)
Power . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . DC 5 V
Version . . . . . . . . . . . Bluetooth Specification Ver. 2.0 + EDR
Output. . . . . . . . . . . . . . . . . . . Bluetooth Specification Class 2
Estimated line-of-sight transmission distance*
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . About 10 m
Frequency range . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2.4 GHz
Modulation
. . . . . . . . . . . FH-SS (Frequency Hopping Spread Spectrum)
Supported Bluetooth profiles . . . . . . . . . . . . . . A2DP, AVRCP
Supported Codec. . . . . . . . . . . . . . . . . SBC (Subband Codec)
Supported contents protection . . . . . . . . . . . . . . . . . SCMS-T
External dimensions
. . . . . . . . . . . . . . . . . 30.5 mm (W) x 9.0 mm (H) x 50 mm (D)
Weight . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . About 11 g
*The line-of-sight transmission distance is an estimate.
Actual transmission distances supported may differ
depending on surrounding conditions.
Miscellaneous
Power requirements . . . . . . . AC 220 V to 230 V, 50 Hz/60 Hz
Power consumption . . . . . . . . . . . . . . . . . . . . . . . . . . . . 410 W
In standby . . . . . . . . 0.2 W ( HDMI Setup – Control : OFF)
0.3 W ( HDMI Setup – Control : ON)
Dimensions . . . . . . 420 mm (W) x 173 mm (H) x 433 mm (D)
Weight (without package)
VSX-LX53 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13.4 kg
VSX-2020 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13.1 kg
Number of Furnished Parts
MCACC Setup microphone (APM7009) . . . . . . . . . . . . . . . . 1
Remote control unit (AXD7592) . . . . . . . . . . . . . . . . . . . . . . . 1
AAA size IEC R03 dry cell batteries . . . . . . . . . . . . . . . . . . . . 2
iPod cable . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
AM loop antenna . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
FM wire antenna . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Bluetooth ADAPTER (AS-BT100) (VSX-LX53 only) . . . . . . . . . 1
Power cord . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Warranty card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Quick start guide
These operating instructions
Note
• Specifications and the design are subject to possible
modifications without notice, due to improvements.
