94
13 Additional information
Specifications
Audio Section
Rated power output (1 kHz, 6 W, 1 %)
Front ..................................... 150 W + 150 W
Center ...................................................150 W
Surround .............................. 150 W + 150 W
Surround back (Front height/wide)
.............................................. 150 W + 150 W
Rated power output
(20 Hz to 20 kHz, 8 W, 0.08 %)
Front ..................................... 110 W + 110 W
Center ...................................................110 W
Surround .............................. 110 W + 110 W
Surround back (Front height/wide)
.............................................. 110 W + 110 W
Total harmonic distortion .......................... 0.06 %
(20 Hz to 20 kHz, 100 W + 100 W, 8 W)
Guaranteed speaker impedance ...... 16 W to 8 W,
less than 8 W to 6 W (setting required)
Signal-to-Noise Ratio
(IHF, short circuited, A network)
LINE .....................................................103 dB
Frequency Response .....5 Hz to 100 000 Hz dB
(Pure Direct Mode)
Input (Sensitivity/Impedance)
LINE .........................................350 mV/47 kW
Output (Level/Impedance)
REC .........................................335 mV/2.2 kW
Tuner Section
Frequency Range (FM) ......87.5 MHz to 108 MHz
Antenna Input (FM) .................. 75 W unbalanced
Frequency Range (AM) ........531 kHz to 1602 kHz
Antenna (AM) .............. Loop antenna (balanced)
Video Section
Signal level
Composite Video .......................1 Vp-p (75 W)
Component Video .............Y: 1.0 Vp-p (75 W),
PB/PR: 0.7 Vp-p (75 W)
Corresponding maximum resolution
Component Video ...................1080p (1125p)
(Video convert off)
Digital In/Out Section
HDMI terminal ............................19-pin (Not DVI)
HDMI output type .................................5 V, 55 mA
USB terminal ............USB2.0 Full Speed (Type A)
iPod terminal ......... USB, and Video (Composite)
ADAPTER PORT terminal ..................5 V, 100 mA
WIRELESS LAN ADAPTER terminal
.............................................................5 V, 600 mA
Integrated Control Section
Control (SR) terminal .....ø 3.5 Mini-jack (MONO)
Control (IR) terminal ......ø 3.5 Mini-jack (MONO)
IR signal ...............High Active (High Level: 2.0 V)
12 V Trigger terminal ......ø 3.5 Mini-jack (MONO)
12 V Trigger output type ..........12 V, Total 150 mA
RS-232C cable type ...................9-pin, cross type,
female-female
EXTENSION terminal .........................5 V, 150 mA
Network Section
LAN terminal .................10 BASE-T/100 BASE-TX
Miscellaneous
Power requirements
............................. AC 220 V to 230 V, 50 Hz/60 Hz
Power consumption ....................................570 W
In standby
.............0.1 W (HDMI Setup – Control : OFF)
.............. 0.3 W (HDMI Setup – Control : ON)
Dimensions
....... 435 mm (W) x 185.6 mm (H) x 440.3 mm (D)
Weight (without package)
VSX-LX55 ............................................... 14 kg
VSX-2021 ............................................. 13.8 kg
Number of Furnished Parts
MCACC Setup microphone ................................ 1
Remote control unit ............................................ 1
AAA size IEC R03 dry cell batteries .................... 2
iPod cable ............................................................ 1
AM loop antenna ................................................. 1
FM wire antenna ................................................. 1
Wireless LAN converter (AS-WL300)
(VSX-LX55 only) ................................................... 1
Warranty card...................................................... 1
Power cord
CD-ROM (AVNavigator)
Quick start guide
Note
! These specifications are applicable when the
power supply is 230 V.
! Specifications and the design are subject to
possible modifications without notice, due to
improvements.
! This product includes FontAvenue ® fonts
licensed by NEC Corporation. FontAvenue is a
registered trademark of NEC Corporation.
En
