Controls and displays 02
9
En
English
Français
Italiano
Español
Nederlands
Deutsch
6 ZONE
Lights when the MULTI-ZONE feature is active
(page 36).
7 Speaker indicator
Shows if the speaker system is on or not
(page 32).
SP  A means the speakers are switched on.
SP  means the speakers are switched off and
sound is output from the headphone jack.
8 Sleep timer indicator
Lights when the receiver is in sleep mode
(page 10).
9 Tuner preset indicators
PRESET
Shows when a preset radio station is
registered or called.
MEM
Blinks when a radio station is registered.
10 PRESET information or input signal
indicator
Shows the preset number of the tuner or the
input signal type, etc.
11 DTS indicators
DTS
Lights when a source with DTS encoded
audio signals is detected.
96/24
Lights when a source with DTS 96/24
encoded audio signals is detected.
12 Character display
Displays various system information.
13 Dolby Digital indicators
2 D
Lights when a Dolby Digital encoded signal
is detected.
2PLll
Lights to indicate Pro Logic II decoding
(see Listening in surround sound on
page 26 for more on this).
14 ADV.S.
Lights when one of the Advanced Surround
modes has been selected (see Using the
Advanced surround effects on page 27 for
more on this).
15 SIGNAL SELECT indicators
DIGITAL
Lights when a digital audio signal is
selected.
Blinks when a digital audio signal is not
selected.
16 DIMMER indicator
Shows when the display is set to turn off as
the DIMMER setting.
17 DIR.
Lights when the
DIRECT or PURE DIRECT
mode is switched on (page 28).
