Removing the Unit

Fig. 5

About the fixing screws for the front panel

Fig. 6

Frame

Pull out to remove the frame.
(When reattaching the frame, point the
side with a groove downwards and
attach it.)

Insert the supplied extraction keys
into the unit, as shown in the figure,
until they click into place. Keeping
the keys pressed against the sides of
the unit, pull the unit out.

If you do not operate the Detaching
and Replacing the Front Panel
Function, use the supplied fixing
screws and fix the front panel to this
unit.

Fixing screw
