7 Diagramm der Abmessungen
Einheiten: mm
50”-Bildschirms bei normalem Gebrauch (ohne die wahlweise mitgelieferten Lautsprecher)
774
150
267
339
508
566
1218
50”-Bildschirm mit den an den beiden Seiten des Bildschirms montierten wahlweise
mitgelieferten Lautsprechern
774
150
267
1368
566
1218
339
508
Lautsprecher
Lautsprecher
