The System Setup menu
39
En
06 06
2 Select ‘Speaker Setting’ from the Manual SP Setup
menu.
3 Choose the set of speakers that you want to set then
select a speaker size.
Use
/ to select the size (and number) of each of the
following speakers:
• Front – Select LARGE if your front speakers reproduce
bass frequencies effectively, or if you didn’t connect a
subwoofer. Select
SMALL to send the bass frequencies to
the subwoofer.
• Center – Select LARGE if your center speaker reproduces
bass frequencies effectively, or select
SMALL to send
bass frequencies to the other speakers or subwoofer. If
you didn’t connect a center speaker, choose
NO (the
center channel is sent to the other speakers).
• Front Height – Select LARGE if your front height
speakers reproduce bass frequencies effectively. Select
SMALL to send bass frequencies to the other speakers or
subwoofer. If you didn’t connect front height speakers
choose
NO.
- VSX-821 only: You can only adjust the Front Height
setting when Pre Out Setting is set to Height.
• Surr – Select LARGE if your surround speakers reproduce
bass frequencies effectively. Select
SMALL to send bass
frequencies to the other speakers or subwoofer. If you
didn’t connect surround speakers choose
NO (the sound
of the surround channels is sent to the other speakers).
• Surr. Back – Select the number of surround back
speakers you have (one, two or none). Select
LARGE if
your surround back speakers reproduce bass frequencies
effectively. Select
SMALL to send bass frequencies to the
other speakers or subwoofer. If you didn’t connect
surround back speakers choose
NO.
- VSX-821 only: You can only adjust the Surr. Back setting
when Pre Out Setting is set to Surr. Back.
- VSX-821 only: If you select one surround back speaker
only, make sure that additional amplifier is hooked up to
the
PRE OUT L (Single) terminal.
- VSX-826 only: When using only one surround back
speaker, connect it to the
SURROUND BACK L (Single)
terminals.
• Subwoofer – LFE signals and bass frequencies of
channels set to
SMALL are output from the subwoofer
when YES is selected (see notes below). Choose the PLUS
setting if you want the subwoofer to output bass sound
continuously or you want deeper bass (the bass
frequencies that would normally come out the front and
center speakers are also routed to the subwoofer). If you
did not connect a subwoofer choose
NO (the bass
frequencies are output from other speakers).
4 When you’re finished, press RETURN.
You return to the Manual SP Setup menu.
Note
• If you select SMALL for the front speakers, the subwoofer
will automatically be fixed to YES. Also, the center,
surround, surround back and front height speakers can’t
be set to
LARGE if the front speakers are set to SMALL. In
this case, all bass frequencies are sent to the subwoofer.
• If the surround speakers are set to NO, the surround back
speakers will automatically be set to NO.
• If you have a subwoofer and like lots of bass, it may seem
logical to select LARGE for your front speakers and PLUS
for the subwoofer. This may not, however, yield the best
bass results. Depending on the speaker placement of
your room you may actually experience a decrease in the
amount of bass due to low frequency cancellations. In
this case, try changing the position or direction of
speakers. If you can’t get good results, listen to the bass
response with it set to
PLUS and YES or the front speakers
set to LARGE and SMALL alternatively and let your ears
judge which sounds best. If you’re having problems, the
easiest option is to route all the bass sounds to the
subwoofer by selecting
SMALL for the front speakers.
Crossover Network
• Default setting: 100Hz
This setting decides the cutoff between bass sounds playing
back from the speakers selected as
LARGE, or the subwoofer,
and bass sounds playing back from those selected as
SMALL. It also decides where the cutoff will be for bass
sounds in the LFE channel.
• For more on selecting the speaker sizes, see Speaker
Setting on page 38.
1 Select ‘Manual SP Setup’ from the System Setup menu.
2 Select ‘Crossover Network’ from the Manual SP Setup
menu.
3 Choose the frequency cutoff point.
Frequencies below the cutoff point will be sent to the
subwoofer (or
LARGE speakers).
4 When you’re finished, press RETURN.
You return to the Manual SP Setup menu.
Channel Level
Using the channel level settings, you can adjust the overall
balance of your speaker system, an important factor when
setting up a home theater system.
1 Select ‘Manual SP Setup’ from the System Setup menu.
2 Select ‘Channel Level’ from the Manual SP Setup menu.
(VSX-826)
2.Manual SP Setup
Return
a.Speaker Setting
b.Crossover Network
c.Channel Level
d.Speaker Distance
2a.Speaker Setting
Front
Front Height
Center
Surr
Surr. Back
Subwoofer:
Return
[ SMALL ]
[ SMALL ]
[ SMALL ]
[ NO ]
YES
SMALL
2.Manual SP Setup
Return
a.Speaker Setting
b.Crossover Network
c.Channel Level
d.Speaker Distance
2b.Crossover Network
Return
Frequency 100Hz
2.Manual SP Setup
Return
a.Speaker Setting
b.Crossover Network
c.Channel Level
d.Speaker Distance
2c.Channel Level
Test Tone Manual
ENTER:Next  Return
