Pioneer VSX-859RDS-G - Manual (Page 39)

39
En
SET
UP
Initial Set up
Channel Level
The following steps show you how to balance the sound output level of your speakers. Proper speaker
balance is essential for obtaining high quality surround sound. If continuing from “Channel Delay” go to
step 1. If starting fresh, complete steps 1 – 3 in “Setting Up for Surround Sound“ (p. 30 – 31) first.
1 Select “Channel Level” (if continuing from
“Channel Delay”, it will already be selected).
See “Setting Up for Surround Sound“ on p. 30 – 31 if you are
unsure how to do this.
Press the ENTER button.
2 Select a TEST TONE mode.
1 Press 5¥∞ to move the cursor to AUTO or MANUAL.
2 Press ENTER to start the test tone.
AUTO (automatic TEST TONE)
This mode switches the test tone between each speaker
automatically.
The test tone is output in the following order (SBL & SBR are
only for the VSX-859RDS):
MANUAL (manual TEST TONE)
This mode lets you switch the test tone between each speaker
manually. You can use this mode when you want to balance the
speaker levels by ear at a more leisurely pace.
The test tone is output in the following order (SBL & SBR are
only for the VSX-859RDS):
3 After pressing ENTER it will take a moment
for the volume to get to the reference position
(0 dB) and the TEST TONE will be output.
These settings will be displayed on your TV.
