BaracodaPencil2 – Programming Guide v1.7 - 24 -
Data Capture
for Workforce
in Motion
Even if the “AIM ID transmit” is disabled, it is possible to enable the AIM ID transmission for EAN128.
Enable AIM ID transmission for EAN128 Disable AIM ID transmission for EAN128 (*)
2.10/ Interleaved 2 of 5 Settings
Interleaved 2 of 5 - not active Interleaved 2 of 5 – active (*)
Interleaved 2 of 5 - check digit - not used (*)
Interleaved 2 of 5 - check digit - mod 10 - checked and transmitted
Interleaved 2 of 5 - check digit - mod 10 - checked but not transmitted
Interleaved 2 of 5 - barcode length - minimum length = 6 (*)
Interleaved 2 of 5 – barcode length- any length
2.11/ MSI Code Settings
MSI Code - not active (*) MSI Code – active
MSI Code - check digit - mod 10 - checked and transmitted (*)
