BaracodaPencil2 – Programming Guide v1.7 - 23 -
Data Capture
for Workforce
in Motion
2.9.2/ EAN 128: Group Separator
‘FNC1’ included in an EAN128 code is transmitted by default as ‘GS’ (Group Separator – 0x1D).
Enable GS transmission (*)
Disable GS transmission
It is possible to replace that ‘GS’ data to an other ASCII data.
Define GS Replacement Character
End of configuration
The common request to replace ‘GS’ by the | (pipe) can be done through the scan of:
Define | as GS
Read « define GS » label
START
Read intermediary label
Corresponding to the next character to set
Finished ?
Read « END of config » label
END
NO
YES
